4. If the disk drive you replaced is the first drive that you could access when you
removed the bottom of the pack, proceed to Step 5 below.
If the drive you replaced is the drive underneath:
• Carefully place the disk drive into the media pack.
• Use a #2 Phillips screwdriver to tighten the four screws (two on each side)
that attach it to the pack; make sure that the heads of the screws are flush
with the side of the pack.
• Repeat Step 2 and Step 3 for the next drive.
5. Use a #2 Phillips screwdriver to tighten the ESD resistor screw on the side of the
disk drive, then put the disk drive into place inside the RXT media pack.
(This may not apply for Green media, depending on the drive you replaced.)
Figure 3-15
6. Secure the disk drive by tightening the screws in the side panels of the RXT
media pack.
Caution: Make sure that all side panel screws are flush with the side of
the RXT media pack so that they do not interfere with loading
and unloading the RXT media.
7. Carefully turn the RXT media pack so that the open side faces up.
Chapter 3. Troubleshooting RXT Media
Tightening the ESD screw.
