Peripheral migration
Table 14. RCC registers used for peripheral access configuration (continued)
Register
Bus
L1 series
RCC_APB2RSTR
APB2
RCC_APB2ENR
RCC_APB2LPENR
1. The register configuring the peripherals is not present in STM32L1 Series, so it should not be needed from a migration-only
stand point
The configuration to access a given peripheral involves:
identifying the bus to which the peripheral is connected, refer to
selecting the right register according the needed action, refer to
For example, USART1 is connected to APB2 bus. In order to enable the USART1 clock, the
RCC_APB2ENR register needs to be configured as follows:
__HAL_RCC_USART1_CLK_ENABLE();
with STM32Cube HAL driver RCC API.
In order to disable USART1 clock during Sleep mode (to reduce power consumption) the
RCC_APB2SMENR register needs to be configured as follows:
__HAL_RCC_USART1_CLK_SLEEP_ENABLE();
with STM32Cube HAL driver RCC API.
4.5.3

Peripheral clock configuration

Some peripherals have a dedicated clock source independent from the system clock, that is
used to generate the clock required for their operation:
USB:
In STM32L1 Series: the USB 48 MHz clock is derived from the PLL VCO clock which
should be at 96 MHz.
In STM32L4 Series: the USB 48 MHz clock is derived from one of the following
sources: main PLL VCO (PLLUSB1CLK), PLLSAI1 VCO (PLLUSB2CLK), MSI clock
(when the MSI clock is auto-trimmed with the LSE, it can be used by the USB OTG FS
device) or HSI48 internal oscillator (only on Cat. 4 devices).
SDIO/SDMMC:
In STM32L1 Series: the SDIO clock (SDIOCLK) is derived from the PLL VCO clock and
is equal to PLLVCO/2.
In STM32L4 Series: the SDMMC clock is derived from one of the three following
sources: main PLL VCO (PLLUSB1CLK), PLLSAI1 VCO (PLLUSB2CLK), MSI clock,
or HSI48 internal oscillator (only for Cat. 4 devices).
RTC and LCD:
The RTC and the LCD Glass clock share the same clock source (RTCCLK).
In STM32L1 Series: the RTC and LCD Glass clock is derived from one of the three
following sources: LSE, LSI, HSE divided by prescaler (/2, 4, 8, 16).
32/58
Register
L4 series
RCC_APB2RSTR
RCC_APB2ENR
RCC_APB2SMENR
DocID027094 Rev 3
Comments
Used to [enter/exit] the APB2 peripheral from
reset
Used to [enable/disable] the APB2 peripheral
clock
Used to [enable/disable] the APB2 peripheral
clock in sleep mode
Table 9 on page 20
Table 14
AN4612
above.
