Operation
Changing the standard display
R oder U can be set as the standard display:
F n
1. Use the up or down buttons to go from the standard display to the display you want.
2. Confirm with Enter.
4.4

Setting the response values (AL)

4.4.1

Response values overview

Display Activation
FAC
R1 < on
R2 < on
U < off
U > off
FAC Factory settings
Cs Customer settings
4.4.2

Setting the insulation resistance parameters

How to proceed
1. Open menu 'AL'.
2. Select parameter 'R1' for prewarning or
parameter 'R2' for alarm.
3. Set value and confirm with Enter.
4.4.3

Setting parameters for undervoltage and overvoltage

How to proceed
1. Open menu 'AL'.
2. Select parameter 'U <' for undervoltage or
parameter 'U >' for overvoltage.
3. Set value and confirm with Enter.
22 isoGEN423_D00221_05_M_XXEN
Cs Range
R2 ... 250
5 ... R1
10 ... U >
U < ... 500
Setting value
FAC
46
23
10
500
Description
Cs
Prewarning value R
k
Hys. = 25 % / min. 1 k
Alarm value R
an2
k
Hys. = 25 % / min. 1 k
Alarm value
V undervoltage RMS
Hys. = 5 % / min. 5 V
Alarm value
V Overvoltage
Hys. = 5 % / min. 5 V
an1
