Bender ISOMETER isoGEN423 Manual page 32

Data access via interfaces
Register
3006
3007
3008
3009
3010
3011
3012
3013
3014
3015
3016
3017
3018
3019
3020
32 isoGEN423_D00221_05_M_XXEN
Property Description
RW Reserved
Alarm value resistance
RW
measurement 'R2'
Activation alarm value
RW
undervoltage 'U <'
Alarm value
RW
undervoltage 'U <'
Activation alarm value
RW
overvoltage 'U >'
Alarm value
RW
overvoltage 'U >'
Memory function
RW for alarm messages
(fault memory) 'M'
Operating mode
RW
of relay 1 'r1'
Operating mode
RW
of relay 2 'r2'
RW Bus address 'Adr'
RW Baud rate 'Adr 1'
RW Parity 'Adr 2'
Start-up delay 't'
RW
during device start
Response delay 'ton'
RW
for relays 'K1' and 'K2'
Delay on release 'toff'
RW
for relays 'K1' and 'K2'
Format Unit
UINT 16 k
UINT 16
UINT 16 V
UINT 16
UINT 16 V
UINT 16
UINT 16
UINT 16
UINT 16
UINT 16
UINT 16
UINT 16 s
UINT 16 s
UINT 16 s
Value range
5 ... R1
0 = Inactive
1 = Active
10 ... U >
0 = Inactive
1 = Active
U < ... 500
0 = Inactive
1 = Active
0 = n.o.
1 = n.c.
0 = n.o.
1 = n.c.
0 / 3 ... 90
0 = BMS
1 = 1.2 k
2 = 2.4 k
3 = 4.8 k
4 = 9.6 k
5 = 19.2 k
6 = 38.4 k
7 = 57.6 k
8 = 115.2 k
0 = 8N1
1 = 8O1
2 = 8E1
0 ...10
0 ... 99
0 ... 99
