Web-based Configuration Guide
parameter
Security Level
Authentication protocol,
authentication password
encryption protocol, encryption
password
Notice
IP of t rap v1/v2c/v3 users cannot be repeated.
12.4.6 Typical configuration examples of the trap service
1. v2c version trap configuration

scenes to be used
When the user is monitoring the device, if the device is suddenly interrupted or abnormal, the third-party
monitoring software cannot detect and deal with the abnormal situation in time, so configure the device with the
destination ip 1 92.1 68.110.85 and port number 1 66 , so that the device sends a trap of the v2c version in case
of an exception.

configuration list
According to the analysis of the user's usage scenario, the requirements are shown in the table:
Table 4-1 User Requirements Description Form
description item
IP and port number
illustrate
Does not contain admin/public/private
Do not contain question marks, spaces and Chinese
Trap user security level, including three levels of authentication and
encryption, authentication and encryption, and authentication and no
encryption
Authentication protocols include:
MD5/SHA/SHA224/SHA256/SHA384/SHA512
Authentication password: 8~ 31 characters in length, cannot contain
Chinese characters, full-width characters, question marks, and spaces,
and must contain at least 3 types of uppercase and lowercase letters,
numbers, or special characters.
Note: This parameter needs to be set when the "Security Level" is
"authentication and encryption" or "authentication without encryption".
Encryption protocols include: DES/AES/AES192/AES256
Encrypted password: the length is 8~ 31 characters, and cannot contain
Chinese, full-width characters, question marks and spaces
format, containing at least 3 types of uppercase and lowercase letters,
numbers, or special characters.
Note: When the "Security Level" is "Authentication and Encryption", this
parameter needs to be set.
illustrate
The target host IP is "192.168.110.85" , and the port number is "166" .
