Ruijie RG-CS86-20XS Series Switches
Hardware Installation and Reference Guide
Document Version: V1.0
Date: 2023.05.05
Copyright © 2023 Ruijie Networks

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RG-CS86-20XS Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ruijie RG-CS86-20XS Series

Summary of Contents for Ruijie RG-CS86-20XS Series

  • Page 1 Ruijie RG-CS86-20XS Series Switches Hardware Installation and Reference Guide Document Version: V1.0 Date: 2023.05.05 Copyright © 2023 Ruijie Networks...
  • Page 2 Due to product version upgrades or other reasons, the content of this document will be updated from time to time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt.
  • Page 3 Preface Intended Audience This document is intended for:  Network engineers  Technical support and servicing engineers  Network administrators Technical Support  Ruijie Networks website: https://www.ruijienetworks.com/  Technical support website: https://ruijienetworks.com/support  Case portal: https://caseportal.ruijienetworks.com  Community: https://community.ruijienetworks.com ...
  • Page 4 Warning An alert that calls attention to important rules and information that if not understood or followed can result in data loss or equipment damage. Caution An alert that calls attention to essential information that if not understood or followed can result in function failure or performance degradation.

  • Page 5: Product Overview

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide 1 Product Overview The RG-CS86-20XS4VS2QXS-D switch is a next-generation L3 switch featured with high performance, high security and multiple services. Mainly applied to the aggregation layer of the campus network, the switch provides multi-layer switching at full line rate and complete end-to-end Quality of Service (QoS) policies, assigning different service flow with different bandwidth and ensuring no delay for key service flow.
  • Page 6 Rated input current: <3 A@90~264 VAC@full load Power < 85 W Consumption Refer to Appendix B Optical Module The supported modules may update at any time. Please contact Ruijie Networks for details. Temperature Support temperature warning and overheat protection. Warning GB/T 9254.1 GB 4943.1 Altitude 0 to 5000 m (16404.2 feet)
  • Page 7 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Appearance The RG-CS86-20XS4VS2QXS-D switch provides 20 10G SFP+ ports, four 25G SFP28 ports , two 40G QSFP+ ports, one MGMT port, one USB port, one Console port, two power slots and two fan slots.
  • Page 8 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Note: 1. Grounding point 3. Power slot 2. Fan slot 4. Asset management asset Product Information Label Figure 1-4 Product Information Label of RG-CS86-20XS4VS2QXS-D Note: The product information label is on the bottom of the switch.
  • Page 9 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide  MGMT port: This is an out-band Ethernet port, which uses standard RJ45 connector. This interface is connected with Ethernet port of a PC to perform program downloading.  SFP+ port: There are 20 10G/1G SFP+ ports, which support optical modules and DAC copper cables, and are compatible with 1000BASE-X.
  • Page 10 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide The SFP+ port is transmitting or receiving data at Blinking green 10G/1G. The SFP28 port is NOT connected. Solid green The SFP28 port is connected at 25G/10G. SFP28 port indicator 21F-24F Blinking green The SFP28 port is transmitting or receiving data at 25G/10G.

  • Page 11: Power Module

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide 1.2 Power Module 1.2.1 RG-PA150I-F The RG-CS86-20XS4VS2QXS-D switch supports RG-PA150I-F. RG-PA150I-F is a smart power module and supports communication with the switch and asset management, including model, version number and SN. The power module can be hot swapped and supports asset management, including model, version number and SN.

  • Page 12: Preparation Before Installation

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Power Model RG-PA150I-F (AC input) RG-PA150I-F (HVDC input) 100 VAC to 240 VAC Rated Voltage 240 VDC 50/60 Hz 90 VAC to 264 VAC Maximum Voltage 192 VDC to 288 VDC 47/63 Hz...

  • Page 13: Safety Precautions

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide 2.1 Safety Precautions To avoid body injury and device damage, please carefully read the safety precautions before you install the RG- CS86-20XS4VS2QXS-D switch. The following safety precautions do not cover all possible dangers.

  • Page 14: Electrostatic Discharge Damage Prevention

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Direct or indirect touch through a wet object on high-voltage and mains supply can bring a fatal danger. The RG-CS86-20XS4VS2QXS-D switch has more than one input power supply. Please unplug all power cables after powering off the switch.

  • Page 15: Installation Site Requirements

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Among the modules supported by the RG-CS86-20XS4VS2QXS-D switch, there are a great number of optical modules that are Class I laser product. Precautions:  When a fiber transceiver works, ensure that the port has been connected with a fiber or has been covered by a dust cap so as to keep out dust and prevent it from burning your eyes.

  • Page 16: System Grounding

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide  In an environment with high relative humidity, the insulating material may have bad insulation or even leak electricity. And sometimes the materials may suffer from mechanical performance change and metallic parts may get rusted.
  • Page 17 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide The device using AC power supply must be grounded by using the yellow/green safety grounding cable. Otherwise, when the insulating resistance decreases between the power supply and the enclosure in the device, electric shock may occur.

  • Page 18: Precaution For Fiber Connection

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide  Effective measures should be taken for the power system to prevent electric grid interference.  The working ground of the routers should be properly separated and kept as far as possible from the grounding device of the power device or the anti-lightning grounding device.

  • Page 19: Product Installation

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide 3 Product Installation The RG-CS86-20XS4VS2QXS-D switch must be used and fixed indoors. Make sure you have carefully read Chapter 2, and be sure that the requirements set forth in Chapter 2 have been met.

  • Page 20: Cabinet Installation

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide  The qualified power supply and current required are available at the installation location.  The related network cables have already been deployed at the installation location. 3.3 Cabinet Installation Precautions When you install the cabinet, pay attention to the following requirements: ...
  • Page 21 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide you should reserve space of at least 10mm between the front panel of the device and that of the cabinet after installation. Before mounting into a cabinet, you need to make sure the following conditions are met: ...
  • Page 22 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide (2) Secure the switch with mounting brackets on the rack rails by tightening the M6 screws. Figure 3-3 Mounting the Switch to a Rack (2) (3) Secure the M6 screws. Figure 3-4 Mounting the Switch to a Rack (3)

  • Page 23: Installing And Removing A Fan Module

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Mounting the Switch to a Workbench In some cases, users do not have the 19-inch standard cabinet. The common solution is to place the switch on a clean workbench. The operation is simple as follows: Attach the four rubber pads to the four corners on the switch bottom.
  • Page 24 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide If the position is not proper, withdraw the inserted module and re-insert it. If the screws cannot be tightened, it is probably because the fan module is not fully inserted. Please check it carefully.
  • Page 25 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Insert the power module smoothly. Please pay attention to the direction of the power panel to avoid wrong insertion. If it is difficult or even impossible to insert the module, pull out the module, make sure the power module and guide rail are well aligned, and then insert the module again.
  • Page 26 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide 3.7 Grounding A PGND is installed on the back of RG-CS86-20XS4VS2QXS-D switch. First connect the PGND to the grounding terminal of the cabinet and then connect the grounding terminal to the grounding bar of the equipment room.

  • Page 27: Binding The Cables

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide 3.10 Binding the Cables Precautions  The power cables and other cables should be bound in a visually pleasing way.  When you bind fibers, be sure that the fibers at the connectors have natural bends or bends of large curvature.

  • Page 28: System Debugging

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide 4 System Debugging 4.1 Establishing the Configuration Environment Establishing the Configuration Environment Connect the PC to the console port of the switch through the console cable, as shown in Figure 4-1. Figure 4-1 Configuration Environment Connecting the Console Cable Connect one end of the DB-9 jack of the console cable to the serial port of the PC.
  • Page 29 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Choose Cancel. The Connection Description window appears as shown in Figure 4-2. Figure 4-2 Enter the name of the new connection and click OK. A window appears as shown in Figure 4-3. In the column of Connect Using field, select the serial port you want to use.

  • Page 30: Power-On Startup

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide After the serial port parameters are set, click OK to enter hyper terminal window. 4.2 Power-on Startup Checking before Power-on  Check if the switch is fully grounded.  Check if the fan module and the power module are correctly installed.

  • Page 31: Monitoring And Maintenance

    Working status of fan and power supply  Temperature status For the monitoring commands, refer to Ruijie RG-CS86-20XS4VS2QXS-D Switches RGOS Configuration Guide. 5.2 Hardware Maintenance Expansion Module Maintenance To replace a board, do replacement according to the instructions provided in Sections of Installing Modules and Removing Modules.
  • Page 32 The built-in lithium batteries can support the real time clock of the RG-CS86-20XS4VS2QXS-D switch without external power supply. Please contact Ruijie technical support for replacing lithium batteries. Replacing the battery with the incorrect model may cause explosion or danger. If the battery is damaged, replace it with the same model.

  • Page 33: General Troubleshooting Procedures

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide 6 Troubleshooting 6.1 General Troubleshooting Procedures Abnormal working after installation Check the cabinet installation Check the mounting of the switch in the cabinet Check the power connection Check the installation of the power supply module...

  • Page 34: Common Issues

    Check whether the configuration of the serial port on the hyper terminal is the same as that described in Ruijie RG-CS86-20XS4VS2QXS-D Switches RGOS Configuration Guide. If not, modify the serial port configuration parameters. If there is still no serial port printed information, please contact Ruijie Customer Service Department for technical support.
  • Page 35 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Such a problem is related to the settings of the serial port. Check if the settings of such parameters as the baud rate match those in Ruijie RG-CS86-20XS4VS2QXS-D Switches RGOS Configuration Guide.

  • Page 36: Appendix A Connectors And Connection Media

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Appendix A Connectors and Connection Media 10GBASE-T/5GBASE-T/2.5GBASE-T/1000BASE-T/100BASE-TX Port 10GBASE-T/5GBASE-T/2.5GBASE-T/1000BASE-T/100BASE-TX is a port that supports self-adaptation of five rates, and automatic MDI/MDIX Crossover at these three rates. 10GBASE-T 10GBASE-T complies with IEEE 802.3an standard, and the supported cables and cabling distances are listed in the following table.
  • Page 37 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Compliant with IEEE 802.3bz, 5GBASE-T requires 100-ohm CAT6 UTP or STP (recommended) with a maximum distance of 100 meters (328 feet). The CAT6 UTP wire must meet TIA TSB-5021 requirements. And the recommended cabling rules are as follows: 1) Avoid mixed cabling with other cables, or use metal clapboard in the trunking to isolate different wires.
  • Page 38 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide 100BASE-TX In addition to the above cables, the 100BASE-TX can use up to 100m of 100-ohm CAT5. Figure A-2 shows the definition of pin signal concerning the 100BASE-TX: Figure A-2 Definition of pin signal concerning the 100BASE-TX...

  • Page 39: Appendix B Mini-Gbic, 10G, 25G, 40G And 100G Module

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Appendix B Mini-GBIC, 10G, 25G, 40G and 100G Module We provide 1000M SFP modules (Mini-GBIC modules), 10G SFP+ modules, 40G QSFP+ modules and 100G modules. according to the types of interfaces of the switch modules. You can select modules to suit your specific needs. The following models and technical specifications of some 1000M SFP modules, 10G SFP+ modules, 40G QSFP+ modules and 100G modules are listed for your reference.
  • Page 40 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide MINI-GBIC-ZX80-SM1550 80km MINI-GBIC-ZX100-SM1550 100km GE-SFP-LX20-SM1310-BIDI 9/125 20km GE-SFP-LX20-SM1550-BIDI 9/125 20km GE-SFP-LH40-SM1310-BIDI 9/125 40km GE-SFP-LH40-SM1550-BIDI 9/125 40km SFP-S4-R1000P1 V1 1310 9/125 10km SFP BIDI Modules Rate/Distance Model GE-SFP-LX20-SM1310-BIDI Gigabit/20km GE-SFP-LX20-SM1550-BIDI GE-SFP-LH40-SM1310-BIDI Gigabit/40km GE-SFP-LH40-SM1550-BIDI BIDI modules must be used in pairs.
  • Page 41 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide interface) XG-SFP-ZR-SM1550 1550 80km interface) 62.5 SFP-M3-R1000P1 2000 300m -7.5 interface) SFP-S1-R1000P1 1310 10km -8.2 -10.3 interface) SFP-S4-R1000P1 V2 1310 10km -8.2 -10.3 interface) The existing 10G SFP+ copper modules: Copper Module...
  • Page 42 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide 300m 2000 (OM3) 40G-QSFP- -7.6 to 2.3 -9.9 to 2.4 (MPO LSR-MM850 400m (Perlane) (Perlane) interface) 4700 (OM4) 40G-QSFP- -7.0 to 2.3 -13.7 to 2.3 1310 10km LR4-SM1310 (Perlane) (Perlane) The existing 40G QSFP+ copper modules:...

  • Page 43: Appendix C Lightning Protection

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Appendix C Lightning Protection Installing AC Power Arrester (lightning protection cable row) The external lightning protection cable row should be used on the AC power port to prevent the switch from being struck by lightning when the AC power cable is introduced from the outdoor and directly connected to the power port of the switch.
  • Page 44 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Installing the Ethernet Port Arrester During the switch usage, the Ethernet port arrester should be connected to the switch to prevent the switch damage by lightning before the outdoor network cable connects to the switch .
  • Page 45 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide You should pay attention to the following conditions during the actual installation to avoid influencing the performance of the Ethernet port arrester:  Reversed direction of the arrester installation. You shall connect the external network cable to the “IN” end and connect the switch Ethernet port to the “OUT”...

  • Page 46: Appendix D Cabling Recommendations In Installation

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Appendix D Cabling Recommendations in Installation When the switches are installed in standard 19-inch cabinets, the cables are tied in the binding rack on the cabinet by the cable management bracket, and top cabling or bottom cabling is adopted according to the actual situation in the equipment room.
  • Page 47 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide  Cables of different types (such as power cords, signal cables, and grounding cables) should be separated in cabling and bundling and no mixed bundling is allowed. When they are close, crossover cabling can be adopted. In the case of parallel cabling, power cords and signal cables should maintain a distance not less than 30 mm.
  • Page 48 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Figure D-3 Bundling up cables (3)  Cables not to be assembled or remaining parts of cables should be folded and placed in a proper position of the cabinet or cabling slot. The proper position indicates a position that will not affect device running or cause device damage or cable damage during commissioning.
  • Page 49 Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Figure D-4 Cable fastening  The hard power cable should be fastened at the terminal connection area to prevent stress on terminal connection and cable.  Do not use self-tapping screws to fasten terminals.

  • Page 50: Appendix E Site Selection

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Appendix E Site Selection  The machine room should be at least 5km away from the heavy pollution source such as the smelter, coal mine and thermal power plant, 3.7km away from the medium pollution source such as the chemical industry, rubber industry and electroplating industry, and 2km away from the light pollution source such as the food manufacturer and leather plant.

  • Page 51: Appendix F Ruijie Intelligent Tech Assistant

    Ruijie RG-CS86-20XS4VS2QXS-D Switches Hardware Installation and Reference Guide Appendix F Ruijie Intelligent Tech Assistant Scan the QR code to get help. · Ruijie Networks Intelligent Service: http://yixiu.ruijie.com.cn:8888/robot/interface/index.html · Ruijie Networks Official Website: https://www.ruijienetworks.com/ · Ruijie Customer Service: 86-4008-111-000...
