Web-based Configuration Guide
Caution
Hot standby is supported only on NBS7006 and NBS7003 series switches.
Only two switches are supported to form a hot standby group.
When multiple switches are configured, select 10GE interfaces as hot standby interfaces to connect the
member switches.
Stacking: refers to physically connecting multiple switches with stack cables, allowing them to operate as a
single logical unit for data forwarding.
(1) Enter the default IP address 10.44.77.200 in the address bar of your browser to go to the web management
interface of the NBS switch. Click the Hot Standby tab (or click Configure in the red box below if the
switch is not yet configured).
(2) Click Start Setup.
6
Login
