Installation and User Guide
U11 #4 Channel Power (max . 32000)
G8 Channel #4 > Manually On/Of
U12 #4 Manually On/Of Time – Set up period of time
for MOn or MOf status (max . 900 minutes)
U13 #4 Status On or Of for mode Heating Manually
U14 #4 Manually On/Of Start or Stop control mode .
Caution: this mode may cause overheating and
damage!
G9 Channel #4 > Channel ON/OFF
U15 #4 Channel ON/OFF If OFF – symbol # in the
line, algorithm is stopped, but real Temp . is
being shown
G11 Channel #4 > Sensor type
U17 #4 Sensor type
G12 Channel #4 > Relay Status RO/RC
U18 #4 Relay status - Set up Relay Opened (RO) or
Relay Closed (RC) for status 'Heating On'
G13 Channel #4 > Relay Test 5/30 sec .
U19 #4 Relay Test 5/30 - Every 5 sec . switching for 30 sec .
H1 Channel #5 > Regulation Type
Y1 #5 Regulation Type: 1S – Single Sensor,
PR – Power Regulation
H2 Channel #5 > Temp & Hysteresis
Y2 #5 Set Temperature
Y3 #5 Set +-Hysteresis
H3 Channel #5 > On Time & Period
Y4 #5 Set On Time
Y5 #5 Set PR Period (max . 900 minutes)
H4 Channel #5 > Alarm Temps & En/Dis
Y6 #5 Alarm Temp En/Dis
Y7 #5 Alarm min . Temp
Y8 #5 Alarm max . Temp
H5 Channel #5 > CableOK?
Y9 #5 CableOK? En/Dis - Enable or Disable the
function of current monitoring in the load
Y10 #5 CableOK? = NO/NC . Set up DI5 status
Normally Opened (NO) or Normally Closed (NC)
when cable is OK
H75 Power calculator > Channel Power #5
Y11 #5 Channel Power (max . 32000)
H8 Channel #5 > Manually On/Of
Y12 #5 Manually On/Of Time – Set up period of time
for MOn or MOf status (max . 900 minutes)
Y13 #5 Status On or Of for mode Heating Manually
FEC | Produced by Danfoss ©
DEVIreg™ Multi
0 32000
1 900
0 1
0 1
0 1
0 7
0 1
0 1
0 1
-50 200
0 .2 6
1 0
0 900
0 1
-50 0
0 200
0 1
0 1
0 32000
1 900
0 1
0 W
1 min .
0 – Of Enum 11
0 – STOP Enum 6
0 – OFF Enum 7
1 – PT1000 Enum 9
0 – RC Enum 10
0 – STOP Enum 6
1 – 1S Enum 1
5 °C
0 .4 °C
15 min .
30 min .
0 – Dis Enum 5
0 °C
60 °C
0 – Dis Enum 5
1 – NO Enum 8
0 W
1 min .
0 – Of Enum 11
RW 3072
RW 3073
RW 3074
RW 3075
RW 3076
RW 3077
RW 3078
RW 3079
RW 3080
RW 3081
RW 3082
RW 3083
RW 3084
RW 3085
RW 3086
RW 3087
RW 3088
RW 3089
RW 3090
RW 3091
RW 3092
