Installation Guide
9 .

Technical specifications and approvals

Danfoss Link™ CC
Operating voltage
Standby power consumption
Screen
Ambient temperature
Storage temperature
Ball pressure temperature
Pollution degree
Transmission frequency
Transmission range in normal buildings
Wi-fi
Max. number of repeaters in a chain
Transmission power
Software class
IP Class
Dimensions
Weight
Danfoss Heating Solutions
Danfoss Link™ CC
VISGL90N
15 V DC ±10%
Max. 2 W
3.5" TFT color with touch
-10 to +40 °C
-20 to +65 °C
75 °C
2 (domestic use)
868.42 MHz
Up to 30 m
802.11b, g or n (2.4 GHz)
3
Max. 1 mW
A
21
125 mm × 107 mm × 25 mm
180 g
GB
12/2014 35
