Proline Prosonic Flow B 200
Display module is attached to the edge of the electronics compartment.
4.
Setting the write protection switch (WP) on the main electronics module to the ON
position enables the hardware write protection.
The Hardware locked option is displayed in the Locking status parameter. In
addition, on the local display the -symbol appears in front of the parameters in
the header of the operational display and in the navigation view.
5.
Feed the spiral cable into the gap between the housing and main electronics module and
plug the display module into the electronics compartment in the desired direction until
it engages.
6.
Reverse the removal procedure to reassemble the transmitter.
10
Diagnostic information
Faults detected by the self-monitoring system of the measuring device are displayed as a
diagnostic message in alternation with the operational display. The message on remedial
measures can be called up from the diagnostic messages, and contains important information
on the fault.
Endress+Hauser
Diagnostic information
39
