Density
Mode Selection
Default Parameter
Motor Protect
Tip Over
Standby Switch
Motor Disabled
Key Sound
*For better performance of SPARKULAR
permission from SHOWVEN
6. DMX Channel Mode
SPARKULAR WAVER occupies 6 operational channels. First channel is for effect height, second
channel for effect trigger and clear material etc.
Channel
CH1
Manual Angle setup
Manual Nozzle Waving
CH2
Speed setup
CH3
Firing ON/OFF
CH4
CH5
Preset sequence setup
CH6
Mode setup
Channel 1 (CH1): Manual Angle Setup
SPARKUALR WAVER output nozzle can be stayed at any angle between -90° to 90°, below is a
list of typical angles used in our preset sequence with related DMX value.
Angle No.
50-100
Factory Mode
User Mode
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
"
WAVER, please don't change the default value without
"
.
Function
0~255: angle change from -90° to 90°
128: straight upward (0°)
0 and 255: Max Speed
1~254: Speed increase
0~15: Firing OFF
16~90: Firing height low
91~170: Firing height medium
171~255: Firing height high
Maxi. Single firing duration is 60s
n/a
Reserved
0-2: no preset sequence
3-255: preset sequence
DMX value = 2 + Sequence No.*2.55 (ROUND OFF)
0~49: Heating Up OFF (Emergency Stop)
50~200: Heating Up ON
201~255: Heating Up OFF (Emergency Stop)
Angle
- 7 -
100
Feeding amount
Factory mode is for engineer only. When
User Mode
in Factory mode machine can't controlled
by DMX console
OFF
Parameters reset to default setting
ON
Motor protect function
Tilt function switch, when machine
slant over 45 degree it will stop
ON
working.
When ON, the machine can firing only
OFF
when heating up was finished
OFF
Motor can't waving when OFF
ON
Keypad press sound setting
Value
DMX value
