Showven SPARKULAR WAVER User Manual page 12

53 (-60°)~ 0° ~ (-60°)
54 (-45°)~ 0° ~ (-45°)
55 (-30°)~ 0° ~ (-30°)
56 90° ~ 0° ~ 90°
57 75° ~ 0° ~ 75°
58 60° ~ 0° ~ 60°
59 45° ~ 0° ~ 45°
60 30° ~ 0° ~ 30°
61 90° ~ 45° ~ 90°
62 90° ~ 30°~ 90°
63 (-90°) ~ (-45°) ~ (-90°)
64 (-90°) ~ (-30°) ~ (-90°)
65 (-90°) ~ 0°
66 90° ~ 0°
67 (-90°) ~ 90°
68 0° ~ (-90°)
69 (-90°) ~ 0°
70 0° ~ 90°
71 90° ~ 0°
72 0°
DMX control example 1: firing sequence No. 42
1. Set output nozzle straight up
CH1 = 128, CH2 = 0, CH3 = 0, CH4 = 0, CH5 = 0, CH6 = 128
2. Set preset Sequence No. 42
CH1 = 128, CH2 = 0, CH3 = 0, CH4 = 0, CH5 = 108, CH6 = 128
3. Firing 1s
CH1 = 128, CH2 = 0, CH3 = 255, CH4 = 0, CH5 = 108, CH6 = 128
DMX control example 2: firing sequence No. 8, firing time 10s
1. Set output nozzle straight up
CH1 = 128, CH2 = 0, CH3 = 0, CH4 = 0, CH5 = 0, CH6 = 128
2. Set preset Sequence No. 8
CH1 = 128, CH2 = 0, CH3 = 0, CH4 = 0, CH5 = 21, CH6 = 128
3. Firing
CH1 = 128, CH2 = 0, CH3 = 255, CH4 = 0, CH5 = 21, CH6 = 128
Keep 10s.
4. Firing OFF
CH1 = 128, CH2 = 0, CH3 = 0, CH4 = 0, CH5 = 0, CH6 = 128
Medium waving 5 times
Medium waving 5 times
Medium waving 5 times
Medium waving 5 times
Medium waving 5 times
Medium waving 5 times
Medium waving 5 times
Medium waving 5 times
Slow waving 3 times
Slow waving 3 times
Slow waving 3 times
Slow waving 3 times
Slow waving gradually
decreases angle
Slow waving gradually
decreases angle
Slow waving gradually
decreases angle
Slow waving once
Slow waving once
Slow waving once
Slow waving once
Fixed angle firing
- 10 -
5s 136-137
4s 138-140
3s 141-142
7s 143-145
6s 146-147
5s 148-150
4s 151-152
3s 153-155
10s 156-158
13s 159-160
10s 161-163
12s 164-165
18s 166-168
19s 169-170
41s 171-173
5s 174-175
5s 176-178
5s 179-180
5s 181-183
Depends
184-185
on CH3
