ReadiConvene IAM Front Panel
The following items appear on the ReadiConvene IAM front panel:
Figure 1-2 shows part of the rear panel of the MGC+50/100 with the
ReadiConvene IAM blade and the MGC+ Control Unit (CU) installed. I/O
cards are inserted via the rear panel. The I/O card for the ReadiConvene
IAM is located on the right side of the MGC+50/100 rear panel. In
addition, the rear panels house the main power switch, AC inlet, fans, fuse,
and additional communications ports.
6
Table 1-1 Polycom ReadiConvene IAM Front Panel
Name LED Color
Power LED Yellow
Not lit
Flash Memory LED Red
Shut Down button NA
Compact Flash NA
Slot
USB port NA
HD LED Red
Remove Server Green
LED
Description
ON
OFF
Read or write enable. Lit when active.
Turns the ReadiConvene IAM blade ON
or OFF.
OFF - Closes all ReadiConvene IAM
processes and applications.
ON - Starts all ReadiConvene IAM
processes and applications.
Future use.
Future use.
Flashes when the hard disk is active.
When lit, you can remove the
ReadiConvene IAM blade. This button is
lit when you press the Shut Down button
on the ReadiConvene IAM.
