4. When the distance is below 20cm or above 80cm, the sensor will send threshold alarm.
Channel
ff
06 (Set Threshold Alarm)
5. Set duration of motion to 50s and duration of stationary to 180s.
Channel
58(Duration of Motion and
ff
ff3e 8c c800 2003 0000 0000
Type
ff5832b4000000
Type
Duration of stationary: b4 00 00 00=00
Stationary)
-END-
Value
CTRL: cc=10 001 100
100=below or above
001=standard mode
10=enable threshold dismiss
report
Min: c8 00 => 00 c8 = 200 mm
= 20 cm
Max: 2003 => 03 20 = 800 mm
= 80cm
Value
Duration of motion: 32=50s
00 00 b4=180s
27
