Parameters
Device EUI
Unique ID of the device which can also be found on the label.
App EUI
Default App EUI is 24E124C0002A0001.
Application Port
The port used for sending and receiving data, default port is 85.
Join Type
OTAA and ABP mode are available.
Application Key
Appkey for OTAA mode, default is 5572404C696E6B4C6F52613230313823.
Device Address
DevAddr for ABP mode, default is the 5
Network Session
Nwkskey for ABP mode, default is 5572404C696E6B4C6F52613230313823.
Key
Application
Appskey for ABP mode, default is 5572404C696E6B4C6F52613230313823.
Session Key
LoRaWAN Version
V1.0.2, V1.0.3 are available.
Work Mode
It's fixed as Class A.
RX2 Data Rate
RX2 data rate to receive downlinks.
RX2 Frequency
RX2 frequency to receive downlinks. Unit: Hz
Channel
Enable or disable the frequency to send uplinks.
Description
th
to 12
th
digits of SN.
10
