EM1300
1D Barcode Scanning Engine
Integration Guide

Advertisement

Table of Contents
loading

Related Manuals for Newland EM1300

Summary of Contents for Newland EM1300

  • Page 1 EM1300 1D Barcode Scanning Engine Integration Guide...
  • Page 2 Version Description Date Pre-release Initial release 20090826 V 1.0 Support as from EM1300 firmware Version 1.13.7 and higher. 20100520 V 1.1 Revise the depth of field on the basis of testing report. 20100817 V 1.2 Revise the pictures of Dimensions 20100902 Revise the pictures of Dimensions, Correct the setting code of "Disable...
  • Page 3 Newland Auto-ID. No right to copy a licensed program in whole or in part is granted except as permitted under copyright law or as hereinafter expressly provided. The user agrees to maintain Newland Auto-ID’s copyright notice on the licensed programs delivered hereunder, and to include the same on any authorized copies it makes in whole or in part.

  • Page 4: Table Of Contents

    Graphic Notations ............................1 Newland Auto-ID Support Center ....................... 2 About EM1300 Introduction ..............................3 Highlights of the EM1300 ........................... 3 Get Familiar With EM1300 ......................... 4 Unpacking ............................. 4 Outline of EM1300 ..........................4 EM1300 Decode Zone ..........................5 Mechanical Interface Introduction ..............................
  • Page 5 Table of Contents EM1300 Development Tools Introduction ..............................18 EM1300 Evaluation Kit, EVK3000 V2 ..................... 19 General Programming Introduction ..............................20 Code Programming ..........................20 Command Programming ........................20 Programming Notation ..........................21 Code Programming ............................ 22 Command Programming ..........................23 Default ...............................
  • Page 6 Table of Contents AIM Prefix ..............................48 Code ID Prefix ............................49 User Suffix ..............................50 Disable or Enable User Suffix ......................50 Program User Suffix ........................... 50 Terminal ..............................51 Disable or Enable Terminal ........................ 51 Program Terminal ..........................51 Symbols Introduction ..............................
  • Page 7 Table of Contents ISBN Digits ............................67 ISBN Code ID ............................. 67 UPC-E ................................ 68 Load Factory Default .......................... 68 Disable/Enable UPC-E ........................68 Check Digit ............................69 UPC-E Code ID ..........................69 2 Digits Addenda Code ........................70 5 Digits Addenda Code ........................70 Transmit Default “0”...
  • Page 8 Table of Contents Industrial 25 ............................... 88 Load Factory Default .......................... 88 Enable/ Disable Industrial 25 ......................88 Industrial 25 Code ID ......................... 88 Check Digit ............................89 Select Message Length ........................90 Standard 25 ..............................91 Load Factory Default .......................... 91 Enable/ Disable Standard 25 .......................
  • Page 9 Table of Contents Check Digit ............................112 Select Message Length ........................113 GS1 Databar ..............................114 Load Factory Default .........................114 Enable/ Disable GS1 Databar ......................114 GS1 Databar Code ID ........................114 Appendix Factory Default List ..........................115 AIM ID List ............................. 121 Code ID List ............................. 122 Digit Code ..............................

  • Page 10: About This Guide

    This NLS-EM1300 (“EM1300”) Scan Engine Integration Guide provides general instructions for OEM integration. Chapter Description About EM1300: The chapter of About EM1300 gives a brief description of the EM1300. It covers the general, overall specifications of the EM1300. Mechanical Interface: The chapter of Mechanical Interface describes the mechanical interface of the EM1300.

  • Page 11: Newland Auto-Id Support Center

    About this guide Newland Auto-ID Support Center If you have a problem with your equipment, contact the Newland Support Center in your region. Before call- ing, have the model number, serial number, and several of your barcodes at hand. Call the support Center from a phone near the scanning equipment so that the service person can try to talk you through your problem.

  • Page 12: About Em1300

    About EM1300 Introduction EM1300 is an embedded barcode reading engine. Its gray scale CCD image capturer and the Newland patented UIMG, a Computerized Image Recognition System, ensure the fast scanning and decoding accuracy on different barcode media such as paper, plastic card, and metal surface. It can be easily integrated into OEM equipments or systems (hand-held, portable, and mounted) to provide solutions for image capture, barcode reading, and barcode message processing.

  • Page 13: Get Familiar With Em1300

    Outline of EM1300 The outline of EM1300 is shown in Figure 1. The topside has the electrical control components, including a flexible cable socket, Interface Socket, through which EM1300 interfaces with external device.

  • Page 14: Em1300 Decode Zone

    About EM1300 EM1300 Decode Zone 42° 55mm Code 39(10mil) 315mm 40mm Code 39(15mil) 430mm 65mm EAN-13(10mil) 250mm 95mm EAN-13(15mil) 310mm 60mm Code 128(10mil) 280mm 40mm Code 128(15mil) 430mm nlscan.com Page 5...

  • Page 15: Mechanical Interface

    Mechanical Interface Introduction This section describes theMechanical Interface. nlscan.com Page 6...

  • Page 16: Dimensions Of Em1300 Unit

    Figure 3. EM1300 Left Side View EM1300 Bottom View The figure 4 EM1300 Bottom View has the mounting screw specifications. The mounting screw is M1.4, 1.4mm screw. The length of the screw into EM1300 must be less than 3 mm. Unit：mm 24.5±0.2...

  • Page 17: Interface

    Interface Cable A 50 mm flexible cable is included in the EM1300 package. Both of the two ends are 12 PINS. One connects to the EM1300 interface socket, the other connects to external device. Figure below shows how the cable is connected to the interface socket.

  • Page 18: Interface Socket Pin Assignment And Definition

    Mechanical Interface Interface Interface Socket Pin Assignment and Definition Pin 12 Pin 1 Type I/O* Description PIN 1 Flash Download Operation Mode Control: Flash Download Mode – Level Low when engine is » powered on; Normal Mode – otherwise. If useres don’t need the »...

  • Page 19: Schematic Of Interface Socket

    Mechanical Interface Interface Schematic of Interface Socket Unit：mm 11 6 5. 5 5 68 4 38 nlscan.com Page 10...

  • Page 20: Interface Flexible Cable Specifications

    Mechanical Interface Interface Interface Flexible Cable Specifications The interface flexible cable is designed by Newland Auto-ID. Unit：mm nlscan.com Page 11...

  • Page 21: Housing Design Considerations

    Mechanical Interface Housing Design Considerations Housing Structure The housing for the Engine should make sure that no pressure should be put on the Engine. There should have sufficient space for the flexible cable and stress release of the cable should also be considered. Scan Window A scan window is needed to protect camera lens and illumination lights.

  • Page 22: Electrical Interface

    Electrical Interface Introduction This section describes the electrical specifications of the interface signals. nlscan.com Page 13...

  • Page 23: Interface Signal Levels

    Electrical Interface Interface Signal levels The table below lists the interface input and output level voltage ranges Signal Type Voltage Level Voltage Range High 2.4V - 3.6V Input -0.3V - 0.6V High 2.9V - 3.3V Output 0V - 0.4V nlscan.com Page 14...

  • Page 24: Input Signals

    Electrical Interface Input signals Trigger Input When the Trigger line is pull low for 10 ms, the Engine starts a read. The Engine keeps reading until a successful reading, a timeout or the line is high. After a successful reading, the line must go high in order to make another read.

  • Page 25: Output Signals

    Electrical Interface Output Signals Here are the descriptions of the output signals, such as Beeper, LED and inter-character timeout. They can be used to detect the status of the scanning, message uploading and the state of the Engine. LED Output When the Engine completes the initialization, the LED line is high.

  • Page 26: A Sample Schematic Of Led Circuit

    Electrical Interface Output Signals A Sample Schematic of LED Circuit Here is the LED circuit used in the evaluation board, EVK3000 V2. DV3.3V GLED R 17 R 13 DLED 2N3906 R 14 100K DGN D A Sample Schematic of Beeper Circuit Here is a beeper circuit used in the evaluation board, EVK3000 V2.

  • Page 27: Em1300 Development Tools

    EM1300 Development Tools Introduction Sections below list some EM1300 development tools. A brief introduction to each tool is included. nlscan.com Page 18...

  • Page 28: Em1300 Evaluation Kit, Evk3000 V2

    EM1300 Evaluation Kit, EVK3000 V2 Here is a brief introduction to the EM1300 Evaluation Kit, EVK3000 V2. The layout of the EVK3000 V2 circuit board is shown in figure below. The board contains beeper and trigger button. A USB connector and an alternative RS232 is for communication.

  • Page 29: General Programming

    General Programming Introduction There are 2 ways to program (configure) the Engine, Code Programming and Command Programming. Code Programming The Engine reads a set of specially encoded barcodes to program options and features. In the following sections, we will explain the options and features available and provide the barcodes to program them. This method of programming the Engine is most straight forward.

  • Page 30: Programming Notation

    General Programming General Programming Programming Notation Tools Code Programming ON Code Programming OFF Code Programming Off 【Pro CMD：99900032】 This is the notation to disable the Code Programming. There are 3 parts of a notation: 1、 The barcode for Code Programming 2、...

  • Page 31: Code Programming

    General Programming General Programming Code Programming Tools Code Programming ON Read the “Code Programming ON” barcode to activate “Code Program- ming” function. More than one Code Programming barcodes can be read to configure the Engine. Code Programming OFF If an option or feature needs additional parameters, such as digits, they can be found at the end of this chapter.

  • Page 32: Command Programming

    General Programming Command Programming Commands under RS232 connection mean using 0x20-0x7D（the displayable characters）to express all commands information. 1、 Configuration State The engine should be in configuration state when programming functions under RS232 connection. In the state, the engine would only accept and execute the commands from communication and feed back.
  • Page 33 General Programming Command Programming 3、Flow Chart Host sends“$$$$” and receives“@@@@” Non-Configuration Configuration 5 seconds timeout， receives“^^^^” State State Host sends“%%%%” and receives“^^^^” Host sends commands， such as“#XXXX ” Receives feedback which Executing Unsuccessful begins with “?”and Commands ends with“;” Successful Receives feedback which Is it a query begins with “!”and...

  • Page 34: Default

    General Programming General Programming Default Tools Code Programming ON Factory Default Read “Load All Factory Default” to reset all parameters to factory default. Code Programming OFF Applicable conditions: User options programming wrong configuration leads to reading mal- » function Forget details of previous programming and start over. »...

  • Page 35: Working Mode

    General Programming General Programming Working Mode Tools Code Programming ON Code Programming OFF Shut Down 【Pro CMD：99900100】 Test Mode 【Pro CMD：99900103】 Deep Sleep 【Pro CMD：99900101】 Restart 【Pro CMD：99900104】 Sleep 【Pro CMD：99900102】 Note: 1、 engine couldn’t be awaked. It must restart or power on. 2、...

  • Page 36: Reading Mode

    General Programming General Programming Reading Mode Tools Code Programming ON Hand-held Mode Factory Default, scan engine will begin to scan when triggered. And when it scans Code Programming OFF successfully or the trigger is released, the engine will stop scanning. Hand-held Mode 【Pro CMD：99900110】...

  • Page 37: Auto Mode

    General Programming General Programming Reading Mode Tools Code Programming ON Auto Mode First program the engine, then trigger it, the engine will start to scan. After a scan, the Code Programming OFF engine will not stop but start a new one automatically until another trigger. By default, the engine will not repeat reading a same barcode.

  • Page 38: Interval Mode

    General Programming General Programming Reading Mode Tools Code Programming ON Interval Mode After programming, the engine will start interval scan without trigger. The interval Code Programming OFF between two scans is fixed whether the scan is successful or not. The value of interval could be programmed by user and the default value is 1s.

  • Page 39: Sensor Mode

    General Programming General Programming Reading Mode Tools Code Programming ON Sensor Mode After programming, the engine will start to sense the environment without trigger. Code Programming OFF After a scan, it will stop and keep sensing to wait another illumination changing. In sensor mode, a trigger also can start a scan.

  • Page 40: Continuous Mode

    General Programming General Programming Reading Mode Tools Code Programming ON Continuous Mode After programming, the engine will be in continuous mode without trigger. After a Code Programming OFF successful scan，the engine will be in waiting state until another scan, then wait again.

  • Page 41: Delayed Sensor Mode

    General Programming General Programming Reading Mode Tools Code Programming ON Delayed Sensor Mode After programming, the engine will start to sense the environment without trigger. Code Programming OFF There will be a delay before a scan. After a scan, it will stop and keep sensing to wait another illumination changing.

  • Page 42: Command Triggered Mode

    General Programming General Programming Reading Mode Tools Code Programming ON Command Triggered Mode After programming, when the engine receives trigger sweep command from Code Programming OFF terminal（e.g. PC）or read "Start Analog Trigger" barcode, the engine will start to work. PS: If reading is successful, data will be returned and the engine wil stop working automatically.

  • Page 43: Security Level

    General Programming General Programming Security Level Tools Code Programming ON The higher the value of Security Level is, the lower the probility of mis-decoding and the decoding speed are. Otherwise, the speed is higher. Code Programming OFF Security Level 1 【Pro CMD：99900120】...

  • Page 44: Beeper

    General Programming General Programming Beeper Tools Code Programming ON Code Programming OFF No Beeper Output 【Pro CMD：99900130】 High Frequency & Loud Volume Low Frequency & Loud Volume 【Pro CMD：99900131】 【Pro CMD：99900137】 High Frequency & Medium Volume Low Frequency & Medium Volume 【Pro CMD：99900132】...

  • Page 45: Others

    General Programming General Programming Others Tools Code Programming ON Start/Stop Temporary Mute Code Programming OFF Temporary Mute Start 【Pro CMD：99900040】 Temporary Mute Stop 【Pro CMD：99900041】 nlscan.com Page 36...

  • Page 46: Query Command

    Query Command Tools Introduction Code Programming ON After reading interrelated programming barcodes, the engine will feed information needed back to the Host to achieve the purpose of query. Code Programming OFF Query Product Information 【Pro CMD：99900300】 Query Manufacturing Date 【Pro CMD：99900303】 Query Hardware Version 【Pro CMD：99900301】...

  • Page 47: Communication Programming

    Communication Programming Introduction Under TTL232 connection the engine and the Host use the same communication parameters: baud rate, parity check, data bits select and stop bits select. nlscan.com Page 38...

  • Page 48: Serial Port Programming

    Communication Setup Serial Port Programming Tools Code Programming ON Under TTL232 connection, the engine and the Host should set communication baud rate to the same to keep normal communication. Baud rate is the bits transmitted per second (8 bits per bytes). The engine and the Code Programming OFF Host must communicate at the same baud rate.

  • Page 49: Check

    Communication Programming Communication Programming Serial Port Programming Tools Code Programming ON Check Code Programming OFF ** No Check 【Pro CMD：99902120】 Even Check 【Pro CMD：99902122】 Odd Check 【Pro CMD：99902121】 nlscan.com Page 40...

  • Page 50: Stop Bit

    Communication Programming Communication Programming Serial Port Programming Tools Code Programming ON Stop Bit Code Programming OFF ** 1 Stop Bit 【Pro CMD：99902131】 2 Stop Bit 【Pro CMD：99902133】 nlscan.com Page 41...

  • Page 51: Flow Control

    Communication Programming Communication Programming Serial Port Programming Tools Code Programming ON Flow Control Code Programming OFF ** No Flow Control 【Pro CMD：99902140】 nlscan.com Page 42...

  • Page 52: Data Bit

    Communication Programming Communication Programming Serial Port Programming Tools Code Programming ON Data Bit Code Programming OFF ** 8 Data Bit 【Pro CMD：99902150】 8 Data Bit, No Check, 2 Stop Bit 【Pro CMD：99902163】 8 Data Bit, No Check, 1 Stop Bit 【Pro CMD：99902160】...
  • Page 53 Communication Programming Communication Programming Serial Port Programming Tools Code Programming ON Code Programming OFF 7 Data Bit 【Pro CMD：99902151】 7 Data Bit, Even Check, 2 Stop Bit 【Pro CMD：99902170】 7 Data Bit, Even Check, 1 Stop Bit 【Pro CMD：99902166】 7 Data Bit, Odd Check, 2 Stop Bit 【Pro CMD：99902171】...

  • Page 54: Data Format

    Data Format Introduction 1D barcodes could contain digits, letters and symbols, etc. 2D barcodes could contain more data, such as Chinese characters and other multi-byte characters. However, in reality, they do not and should not have enough information we need, such as barcode type, date and time of scan, delimiter, and so on, in order to keep the code short and flexible.

  • Page 55: Prefix Sequences

    Data Format Data Format Prefix Sequences Tools Code Programming ON Code Programming OFF CodeID+User Prefix+AIMID 【Pro CMD：99904010】 User Prefix+CodeID+AIMID 【Pro CMD：99904011】 nlscan.com Page 46...

  • Page 56: User Prefix

    Data Format Data Format User Prefix Tools Code Programming ON Disable or Enable User Prefix Code Programming OFF User Prefix is added before barcode message. For example, if the user prefix is “AB” and the barcode message is “123”, the Host receives “AB123”.

  • Page 57: Aim Prefix

    Data Format Data Format AIM Prefix Tools Code Programming ON AIM (Automatic Identification Manufactures) defines AIM prefix for many standard barcode formats. The engine will add the identifier before the barcodes. And this identifier is the AIM Prefix. And please see Appendix to find the AIM Code Programming OFF ID list.

  • Page 58: Code Id Prefix

    Data Format Data Format Code ID Prefix Tools Code Programming ON Besides AIM prefix, Code ID prefix can be used to denote barcode format and can be customized. Code Programming OFF The Code ID prefix MUST be one (1) or two(2) visible English letters, capital or small, only.

  • Page 59: User Suffix

    Data Format Data Format User Suffix Tools Code Programming ON Disable or Enable User Suffix Code Programming OFF User suffix is appended to the right of barcode message. For example, if user suffix is “AB”, and the barcode message is “123”, The Host receives “123AB”. Disable User Suffix 【Pro CMD：99904100】...

  • Page 60: Terminal

    Data Format Data Format Terminal Tools Code Programming ON Disable or Enable Terminal “Terminal” is the termination for a string of barcode messages. It is fixed to the Code Programming OFF right and the very end of a barcode transmission. The major difference between "Terminal"...

  • Page 61: Introduction

    Symbols Introduction Each type of barcode has its unique attribute. With the programming code, the engine will adjust to the changes of these attributes. Disabling reading of the symbols which do not apply will improve reading performance. nlscan.com Page 52...

  • Page 62: Code 128

    Symbols Code 128 Tools Code Programming ON Load Factory Default Code Programming OFF Load Code 128 Factory Default 【Pro CMD：99910000】 Enable/Disable Code 128 Enable Code 128 【Pro CMD：99910002】 Disable Code 128 【Pro CMD：99910001】 When the engine can not read Code 128, please read“Enable Code 128” and try again. Code 128 Code ID Code ID Setting 【Pro CMD：99910005】...

  • Page 63: Select Message Length

    Symbols Code 128 Tools Code Programming ON Select Message Length It is used to program the valid reading length of Code 128. The engine will send an error beep, if the decoded data length does not match the valid Code Programming OFF length.

  • Page 64: Ucc/Ean-128

    Symbols UCC/EAN-128 Tools Code Programming ON Load Factory Default Code Programming OFF Load UCC/EAN-128 Factory Default 【Pro CMD：99910100】 Enable/Disable UCC/EAN-128 Enable UCC/EAN-128 【Pro CMD：99910102】 Disable UCC/EAN-128 【Pro CMD：99910101】 When the engine can not read UCC/EAN-128, please read “Enable UCC/EAN-128” and try again.

  • Page 65: Select Message Length

    Symbols UCC/EAN-128 Tools Code Programming ON Select Message Length It is used to program the valid reading length of UCC/EAN-128. The engine will send an error beep, if the decoded data length does not match the valid Code Programming OFF length.

  • Page 66: Aim 128

    Symbols AIM 128 Tools Code Programming ON Load Factory Default Code Programming OFF Load AIM 128 Factory Default 【Pro CMD：99910200】 Enable/Disable AIM 128 Enable AIM 128 【Pro CMD：99910202】 Disable AIM 128 【Pro CMD：99910201】 When the engine can not read AIM 128, please read “Enable AIM 128” and try again. AIM 128 Code ID Code ID Setting 【Pro CMD：99910205】...

  • Page 67: Select Message Length

    Symbols AIM 128 Tools Code Programming ON Select Message Length It is used to program the valid reading length of AIM 128. The engine will send an error beep, if the decoded data length does not match the valid length. Code Programming OFF AIM 128 Message Length is defined by “Min.

  • Page 68: Load Factory Default

    Symbols EAN-8 Tools Code Programming ON Load Factory Default Code Programming OFF Load EAN-8 Factory Default 【Pro CMD：99910400】 Enable/Disable EAN-8 Enable EAN-8 【Pro CMD：9991402】 Disable EAN-8 【Pro CMD：99910401】 When the engine can not read EAN-8, please read “Enable EAN-8” and try again. EAN-8 Code ID Code ID Setting 【Pro CMD：99910416】...

  • Page 69: Digits Addenda Code

    Symbols EAN-8 Tools Code Programming ON 2 Digits Addenda Code 2 Digits Addenda Code is the one to the right of an ordinary code. Code Programming OFF Disable 2 Digits Addenda Code 【Pro CMD：99910405】 Only Read With 2 digits Addenda Code 【Pro CMD：99910407】...

  • Page 70: Expand To Ean-13

    Symbols EAN-8 Tools Code Programming ON EAN-8 expand to EAN-13 “ Do Not Expand to EAN-13 “ — keep original type and digits, do not Code Programming OFF expand. “Expand to EAN-13 by Adding Leading 0s “ — expand to EAN-13 but keep code type.

  • Page 71: Load Factory Default

    Symbols EAN-13 Tools Code Programming ON Load Factory Default Code Programming OFF Load EAN-13 Factory Default 【Pro CMD：99910500】 Disable/Enable EAN-13 Enable EAN-13 【Pro CMD：99910502】 Disable EAN-13 【Pro CMD： 99910501 】 When the engine can not read EAN-13, please read “Enable EAN-13” and try again. nlscan.com Page 62...

  • Page 72: Check Digit

    Symbols EAN-13 Tools Code Programming ON Check Digit EAN-13 is fixed 13 digits barcode and the last digit is check digit. Check digit Code Programming OFF is a value caculated from all digits. It is used for checking if the all 13 digits are right.

  • Page 73: Digits Addenda Code

    Symbols EAN-13 Tools Code Programming ON 2 Digits Addenda Code 2 Digits Addenda Code is the one to the right of an ordinary code. Code Programming OFF Disable 2 Digits Addenda Code 【Pro CMD：99910505】 Only Read With 2 digits Addenda Code 【Pro CMD：99910507】...

  • Page 74: Issn

    Symbols ISSN Tools Code Programming ON Load Factory Default Code Programming OFF Load ISSN Factory Default 【Pro CMD：99910600】 Enable/Disable ISSN Enable ISSN 【Pro CMD：99910602】 Disable ISSN 【Pro CMD：99910601】 When the engine can not read ISSN, please read “Enable ISSN” and try again. ISSN Code ID Code ID Setting 【Pro CMD：99910603】...

  • Page 75: Isbn

    Symbols ISBN Tools Code Programming ON Load Factory Default Code Programming OFF Load ISBN Factory Default 【Pro CMD：99910700】 Enable/Disable ISBN Enable ISBN 【Pro CMD：99910702】 Disable ISBN 【Pro CMD：99910701】 When the engine can not read ISBN, please read “Enable ISBN” and try again. nlscan.com Page 66...

  • Page 76: Isbn Digits

    Symbols ISBN Tools Code Programming ON ISBN Digits Code Programming OFF Use 13 Digits 【Pro CMD：99910704】 Use 10 Digits 【Pro CMD：99910703】 ISBN Code ID Code ID Setting 【Pro CMD：99910705】 Example of setting ISBN Code ID to “p” (0x70) 1. Read Enable Code Programming barcode. 2.

  • Page 77: Upc-E

    Symbols UPC-E Tools Code Programming ON Load Factory Default Code Programming OFF Load UPC-E Factory Default 【Pro CMD：99911000】 Disable/Enable UPC-E Enable UPC-E 【Pro CMD：99911002】 Disable UPC-E 【Pro CMD：99911001】 When the engine can not read UPC-E, please read “Enable UPC-E” and try again. nlscan.com Page 68...

  • Page 78: Check Digit

    Symbols UPC-E Tools Code Programming ON Check Digit UPC-E is fixed 8 digits barcode and the last digit is check digit. Check digit Code Programming OFF is a value caculated from all digits. It is used for checking if the all 8 digits are right.

  • Page 79: Digits Addenda Code

    Symbols UPC-E Tools Code Programming ON 2 Digits Addenda Code 2 Digits Addenda Code is the one to the right of an ordinary code. Code Programming OFF Disable 2 Digits Addenda 【Pro CMD：99911005】 Only Read With 2 digits Addenda Code 【Pro CMD：99911007】...

  • Page 80: Transmit Default "0

    Symbols UPC-E Tools Code Programming ON Transmit Default “0” The first byte of UPC-E is default to “0”. Code Programming OFF Do Not Transmit “0” 【Pro CMD：99911013】 Transmit “0” 【Pro CMD：99911014】 UPC-E Expand to UPC-A “ Do Not Expand “ — keep original type and digits, do not expand. “Expand to UPC-A “...

  • Page 81: Upc-A

    Symbols UPC-A Tools Code Programming ON Load Factory Default Code Programming OFF Load UPC-A Factory Default 【Pro CMD：99911100】 Disable/Enable UPC-A Enable UPC-A 【Pro CMD：99911102】 Disable UPC-A 【Pro CMD：99911101】 When the engine can not read UPC-A, please read “Enable UPC-A” and try again. UPC-A Code ID Code ID Setting 【Pro CMD：99911115】...

  • Page 82: Check Digit

    Symbols UPC-A Tools Code Programming ON Check Digit UPC-A is fixed 13 digits barcode and the last digit is check digit. Check digit Code Programming OFF is a value caculated from all digits. It is used for checking if the all 13 digits are right.

  • Page 83: Digits Addenda Code

    Symbols UPC-A Tools Code Programming ON 2 Digits Addenda Code 2 Digits Addenda Code is the one to the right of an ordinary code. Code Programming OFF Disable 2 Digits Addenda Code 【Pro CMD：99911105】 Only Read With 2 digits Addenda Code 【Pro CMD：99911107】...

  • Page 84: Interleaved 2 Of 5

    Symbols Interleaved 2 of 5 Tools Code Programming ON Load Factory Default Code Programming OFF Load Interleaved 2 of 5 Factory Default 【Pro CMD：99911200】 Disable/Enable Interleaved 2 of 5 Enable Interleaved 2 of 5 【Pro CMD：99911202】 Disable Interleaved 2 of 5 【Pro CMD：99911201】...

  • Page 85: Check Digit

    Symbols Interleaved 2 of 5 Tools Code Programming ON Check Digit Interleaved 2 of 5 may include Check Digit (not compulsory) following its barcode messages. If included, it could be the last digit. It verifies the barcode Code Programming OFF message.

  • Page 86: Select Message Length

    Symbols Interleaved 2 of 5 Tools Code Programming ON Select Message Length It is used to program the valid reading length of Interleaved 2 of 5. The engine Code Programming OFF will send an error beep, if the decoded data length does not match the valid length.

  • Page 87: Code Id

    Symbols ITF-6 Tools Code Programming ON ITF-6 is a fixed length 6 bytes Interleaved 2 of 5 barcode with check digit. When enabled, ITF-6 precedes 6-byte Interleaved 2 of 5 barcode. Code Programming OFF Load ITF-6 Factory Default 【Pro CMD：99911300】 Enable ITF-6, Do Not Transmit Check Digit 【Pro CMD：99911301】...

  • Page 88: Code Id

    Symbols ITF-14 Tools Code Programming ON ITF-14 is a fixed length of 14 bytes Interleaved 2 of 5 barcode with Check digit. By factory default, it is disabled. Code Programming OFF When enabled, ITF-14 precedes 14-byte Interleaved 2 of 5 barcode. Load ITF-14 Factory Default 【Pro CMD：99911400】...

  • Page 89: Deutshe14

    Symbols Deutshe14 Tools Code Programming ON Load Factory Default Code Programming OFF Load Deutshe14 Factory Default Deutshe14 Factory Default Factory Default 【Pro CMD：99911500】 Disable/Enable Deutshe14 Enable Deutshe14，Do Not Transmit Check Digit 【Pro CMD：99911502】 Disable Deutshe14 【Pro CMD：99911501】 Enable Deutshe14， Transmit Check Digit 【Pro CMD：99911503】...

  • Page 90: Deutshe12

    Symbols Deutshe12 Tools Code Programming ON Load Factory Default Code Programming OFF Load Deutshe12 Factory Default Deutshe12 Factory Default Factory Default 【Pro CMD：99911600】 Disable/Enable Deutshe12 Enable Deutshe12，Do Not Transmit Check Digit 【Pro CMD：99911602】 Disable Deutshe12 【Pro CMD：99911601】 Enable Deutshe12， Transmit Check Digit 【Pro CMD：99911603】...

  • Page 91: Coop25（Japanese Matrix 2 Of 5

    Symbols COOP25（Japanese Matrix 2 of 5） Tools Code Programming ON Load Factory Default Code Programming OFF Load COOP25 Factory Default 【Pro CMD：99911700】 Enable/ Disable COOP25 Enable COOP25 【Pro CMD：99911702】 Disable COOP25 【Pro CMD：99911701】 When the engine can not read COOP25, please read “Enable COOP25” and try again. COOP25（Japanese Matrix 2 of 5）...

  • Page 92: Check Digit

    Symbols COOP25（Japanese Matrix 2 of 5） Tools Code Programming ON Check Digit COOP25 may include Check Digit (not compulsory) following its barcode Code Programming OFF messages. If included, it may be the last digit. It verifies the barcode message. “NO Check, Transmit All” means to read without check and transmit »...

  • Page 93: Select Message Length

    Symbols COOP25（Japanese Matrix 2 of 5） Tools Code Programming ON Select Message Length It is used to program the valid reading length of COOP25. The engine will Code Programming OFF send an error beep, if the decoded data length does not match the valid length. COOP25 Message Length is defined by “Min.

  • Page 94: Matrix 2 Of 5( European Matrix 2 Of 5)

    Symbols Matrix 2 of 5( European Matrix 2 of 5) Tools Code Programming ON Load Factory Default Code Programming OFF Load Matrix 2 of 5 Factory Default 【Pro CMD： 99912000 】 Enable/ Disable Matrix 2 of 5 Enable Matrix 2 of 5 【Pro CMD：99912002】...

  • Page 95: Check Digit

    Symbols Matrix 2 of 5( European Matrix 2 of 5) Tools Code Programming ON Check Digit Matrix 2 of 5 may include Check Digit (not compulsory) following its barcode Code Programming OFF messages. If included, it may be the last digit. It verifies the barcode message. “NO Check, Transmit All”...

  • Page 96: Select Message Length

    Symbols Matrix 2 of 5( European Matrix 2 of 5) Tools Code Programming ON Select Message Length It is used to program the valid reading length of Matrix 2 of 5. The engine will Code Programming OFF send an error beep, if the decoded data length does not match the valid length. Matrix 2 of 5 Message Length is defined by “Min.

  • Page 97: Industrial 25

    Symbols Industrial 25 Tools Code Programming ON Load Factory Default Code Programming OFF Load Industrial 25 Factory Default 【Pro CMD：99912100】 Enable/ Disable Industrial 25 Enable Industrial 25 【Pro CMD：99912102】 Disable Industrial 25 【Pro CMD：99912101】 When the engine can not read Industrial 25, please read “Enable Industrial 25” and try again.

  • Page 98: Check Digit

    Symbols Industrial 25 Tools Code Programming ON Check Digit Industrial 25 may include Check Digit (not compulsory) following its Code Programming OFF barcode messages. If included, it may be the last digit. It verifies the barcode message. “NO Check, Transmit All” means to read without check and trans- »...

  • Page 99: Select Message Length

    Symbols Industrial 25 Tools Code Programming ON Select Message Length It is used to program the valid reading length of Industrial 25. The engine Code Programming OFF will send an error beep, if the decoded data length does not match the valid length.

  • Page 100: Standard 25

    Symbols Standard 25 Tools Code Programming ON Load Factory Default Code Programming OFF Load Standard 25 Factory Default 【Pro CMD：99912200】 Enable/ Disable Standard 25 Enable Standard 25 【Pro CMD：99912202】 Disable Standard 25 【Pro CMD：99912201】 When the engine can not read Standard 25, please read “Enable Standard 25” and try again. Standard 25 Code ID Code ID Setting 【Pro CMD：99912210】...

  • Page 101: Check Digit

    Symbols Standard 25 Tools Code Programming ON Check Digit Standard 25 may include Check Digit (not compulsory) following its Code Programming OFF barcode messages. If included, it may be the last digit. It verifies the barcode message. “NO Check, Transmit All” means to read without check and trans- »...

  • Page 102: Select Message Length

    Symbols Standard 25 Tools Code Programming ON Select Message Length It is used to program the valid reading length of Standard 25. The engine Code Programming OFF will send an error beep, if the decoded data length does not match the valid length.

  • Page 103: Code 39

    Symbols Code 39 Tools Code Programming ON Load Factory Default Code Programming OFF Load Code 39 Factory Default 【Pro CMD：99912400】 Enable/Disable Code 39 Enable Code 39 【Pro CMD：99912402】 Disable Code 39 【Pro CMD：99912401】 When the engine can not read Code 39, please read “Enable Code 39” and try again Code 39 Code ID Code ID Setting 【Pro CMD：99912414】...

  • Page 104: Check Digit

    Symbols Code 39 Tools Code Programming ON Check Digit Code 39 may include Check Digit (not compulsory) following its barcode message. It verifies the barcode message. Code Programming OFF "NO Check, Transmit All" means to read without check and transmit »...

  • Page 105: Transmit Start & Stop Character

    Symbols Code 39 Tools Code Programming ON Transmit Start & Stop Character Code 39 has one "*" before and another after digits as Start & Stop Character. Code Programming OFF Transmission of “*” can be selected. Transmit Both “*” 【Pro CMD：99912407】 Transmit Neither “*”...

  • Page 106: Select Message Length

    Symbols Code 39 Tools Code Programming ON Select Message Length Code 39 Message Length is defined by “Min. Message Length” and Code Programming OFF “Max. Message Length “.It is used to program the valid reading length of Code 39. The engine will send an error beep, if the decoded data length does not match the valid length.

  • Page 107: Codabar

    Symbols Codabar Tools Code Programming ON Load Factory Default Code Programming OFF Load Codabar Factory Default 【Pro CMD：99912500】 Enable/Disable Codabar Enable Codabar 【Pro CMD：99912502】 Disable Codabar 【Pro CMD：99912501】 When the engine can not read Codabar, please read “Enable Codabar” and try again. Codabar Code ID Code ID Setting 【Pro CMD：99912516】...

  • Page 108: Check Digit

    Symbols Codabar Tools Code Programming ON Check Digit Codabar may include Check Digit (not compulsory) following its barcode message. It verifies the barcode message. Code Programming OFF "NO Check, Transmit All" means to read without check and transmit » all bytes including barcode message and Check Digit. "Check, Do Not Transmit Check Digit"...

  • Page 109: Transmit Start & Stop Character

    Symbols Codabar Tools Code Programming ON Transmit Start & Stop Character Code Programming OFF Do Not Transmit Both Start & Stop Character 【Pro CMD：99912506】 Transmit Both Start & Stop Character 【Pro CMD：99912507】 Use ABCD/ABCD As Start & Stop Character 【Pro CMD：99912510】 Use ABCD/TN*E As Start &...

  • Page 110: Select Message Length

    Symbols Codabar Tools Code Programming ON Select Message Length Codabar Message Length is defined by “Min. Message Length” and Code Programming OFF “Max. Message Length “.It is used to program the valid reading length of Codabar. The engine will send an error beep, if the decoded data length does not match the valid length.

  • Page 111: Code 93

    Symbols Code 93 Tools Code Programming ON Load Factory Default Code Programming OFF Load Code 93 Factory Default 【Pro CMD：99912600】 Enable /Disable Code 93 Enable Code 93 【Pro CMD：99912602】 Disable Code 93 【Pro CMD：99912601】 When the engine can not read Code 93, please read “Enable Code 93” and try again. Code 93 Code ID Code ID Setting 【Pro CMD：99912610】...

  • Page 112: Check Digit

    Symbols Code 93 Tools Code Programming ON Check Digit Code 93 may include Check Digits (not compulsory) following its barcode message. If included, they are the last two digits. They verifie the barcode Code Programming OFF message. "NO Check, Transmit All" means to read without check and transmit »...

  • Page 113: Select Message Length

    Symbols Code 93 Tools Code Programming ON Select Message Length It is used to program the valid reading length of Code 93. The engine will Code Programming OFF send an error beep, if the decoded data length does not match the valid length.

  • Page 114: Code 11

    Symbols Code 11 Tools Code Programming ON Load Factory Default Code Programming OFF Load Code 11 Factory Default 【Pro CMD：99912700】 Enable/ Disable Code 11 Enable Code 11 【Pro CMD：99912702】 Disable Code 11 【Pro CMD：99912701】 When the engine can not read Code 11, please read “Enable Code 11” and try again. Code 11 Code ID Code ID Setting 【Pro CMD：99912715】...

  • Page 115: Check Digit

    Symbols Code 11 Tools Code Programming ON Check Digit Code 11 may include Check Digit (not compulsory) following its barcode Code Programming OFF messages. If included, it may be the last one or two digits. It verifies the barcode message. “NO Check, Transmit All”...

  • Page 116: Select Message Length

    Symbols Code 11 Tools Code Programming ON Select Message Length It is used to program the valid reading length of Code 11. The engine will Code Programming OFF send an error beep, if the decoded data length does not match the valid length.

  • Page 117: Plessey

    Symbols Plessey Tools Code Programming ON Load Factory Default Code Programming OFF Load Plessey Factory Default 【Pro CMD：99913000】 Enable/ Disable Plessey Enable Plessey 【Pro CMD：99913002】 Disable Plessey 【Pro CMD：99913001】 When the engine can not read Plessey, please read “Enable Plessey” and try again. Plessey Code ID Code ID Setting 【Pro CMD：99913010】...

  • Page 118: Check Digit

    Symbols Plessey Tools Code Programming ON Check Digit Plessey may include Check Digits (not compulsory) following its barcode Code Programming OFF messages. If included, they are the last two digit. They verifie the barcode message. “NO Check, Transmit All” means to read without check and transmit »...

  • Page 119: Select Message Length

    Symbols Plessey Tools Code Programming ON Select Message Length It is used to program the valid reading length of Plessey. The engine will Code Programming OFF send an error beep, if the decoded data length does not match the valid length.

  • Page 120: Msi-Plessey

    Symbols MSI-Plessey Tools Code Programming ON Load Factory Default Code Programming OFF Load MSI-Plessey Factory Default 【Pro CMD：99913100】 Enable/ Disable MSI-Plessey Enable MSI-Plessey 【Pro CMD：99913102】 Disable MSI-Plessey 【Pro CMD：99913101】 When the engine can not read MSI-Plessey, please read “Enable MSI-Plessey” and try again. MSI-Plessey Code ID Code ID Setting 【Pro CMD：99913113】...
  • Page 121 Symbols MSI-Plessey Tools Code Programming ON Check Digit MSI-Plessey may include Check Digit (not compulsory) following its Code Programming OFF barcode messages. If included, it may be the last one or two digits. It verifies the barcode message. “NO Check, Transmit All” means to read without check and trans- »...
  • Page 122 Symbols MSI-Plessey Tools Code Programming ON Select Message Length MSI-Plessey Message Length is defined by “Min. Message Length” and Code Programming OFF “Max. Message Length ”.It is used to program the valid reading length of MSI-Plessey. The engine will send an error beep, if the decoded data length does not match the valid length.
  • Page 123 Symbols GS1 Databar Tools Code Programming ON Load Factory Default Code Programming OFF Load GS1 Databar Factory Default 【Pro CMD：99913200】 Enable/ Disable GS1 Databar Enable GS1 Databar 【Pro CMD：99913202】 Disable GS1 Databar 【Pro CMD：99913201】 When the engine can not read GS1 Databar, please read “Enable GS1 Databar” and try again. GS1 Databar Code ID Code ID Setting 【Pro CMD：99913203】...
  • Page 124 Appendix Factory Default List Parameters Factory Default Remark General Programming Code Programming Send Pro Code Value Working Mode Hand-held Mode Range：0-15s， Reading a Barcode Time Length 0 is infinite time. Interval Length Range：0-7.5s Sensitivity High Sensitivity Enabled in Sensor Mode Security Level Level 1 Medium Frequency &...
  • Page 125 Appendix Factory Default List Parameters Factory Default Remark Symbol Code 128 Enable Max Message Length Min Message Length UCC/EAN-128 Enable Max Message Length Min Message Length AIM 128 Enable Min Message Length EAN-8 Enable Send Check Digit Enable 2 Digits Addenda Code Enable 5 Digits Addenda Code Only Read With 2 digits Addenda Code Only Read With 5 digits Addenda Code...
  • Page 126 Appendix Factory Default List ISSN Enable ISBN Enable Use 10 Digits UPC-E Enable Send Check Digit Enable 2 Digits Addenda Code Enable 5 Digits Addenda Code Only Read With 2 digits Addenda Code Only Read With 5 digits Addenda Code Expand to UPC-A Expand and Change Type to UPC-A Send Default“0”...
  • Page 127 Appendix Factory Default List Deutsche 14 Enable Send Check Digit Deutsche 12 Enable Send Check Digit COOP 25(Japanese Matrix 2 of 5) Enable Check Send Check Digit Max Message Length Min Message Length No less than 4 data bits Matrix 2 of 5(European Matrix 2 of 5) Enable Check Send Check Digit...
  • Page 128 Appendix Factory Default List Support Full ASCII Max Message Length No less than 4 (including Start & Min Message Length Stop Character) Codabar Enable Check Send Check Digit Send Start & Stop Character ABCD/ABCD as Start & Stop Character ABCD/TN*E as Start & Stop Character Choose 1 In 4 abcd/abcd as Start &...
  • Page 129 Appendix Factory Default List Max Message Length Min Message Length No less than 1 data bit MSI-Plessey Enable Send Check Digit Check 1 Digit, MOD10 Check 2 Digits, MOD10/MOD10 Check 2 Digits, MOD10/MOD11 Check Max Message Length Min Message Length No less than 1 data bit GS1 Databar Enable...
  • Page 130 Appendix AIM ID List Possible AIM ID Symbol AIM ID Modifiers(m) Code 128 UCC/EAN-128 AIM 128 ISBT 128 EAN-8 EAN-13 EAN-13 with Addon ISSN ISBN UPC-E UPC-E with Addon UPC-A UPC-A with Addon 0,1,3 Interleaved 2 of 5 ITF-6 ITF-14 Deutsche 14 Deutsche 12 COOP 25（Japanese Matrix 2 of 5）...
  • Page 131 Appendix Code ID List Symbol Code ID Code 128 UCC/EAN-128 AIM 128 ISBT 128 EAN-8 EAN-13 ISSN ISBN UPC-E UPC-A Interleaved 2 of 5 ITF-6 ITF-14 Deutsche 14 Deutsche 12 COOP 25（Japanese Matrix 2 of 5） Matrix 2 of 5(European Matrix 2 of 5) Industrial 25 Standard 25 Code 39...
  • Page 132 Appendix Appendix Digit Code Tools Code Programming ON It is must to read save after reading digit code. Code Programming OFF 【Pro CMD：99900000】 【Pro CMD：99900004】 【Pro CMD：99900001】 【Pro CMD：99900005】 【Pro CMD：99900002】 【Pro CMD：99900006】 【Pro CMD：99900003】 【Pro CMD：99900007】 nlscan.com Page 123...
  • Page 133 Appendix Digit Code Tools Code Programming ON Code Programming OFF 【Pro CMD：99900010】 【Pro CMD：99900014】 【Pro CMD：99900011】 【Pro CMD：99900015】 【Pro CMD：99900012】 【Pro CMD：99900016】 【Pro CMD：99900013】 【Pro CMD：99900017】 nlscan.com Page 124...
  • Page 134 Appendix Appendix Save and Abort Tools Tools Code Programming ON Code Programming ON In order to save the received data “Save” has to be read after data transition completed. If error occurs when reading data, the wrong data can be deleted and the setting up can be done again.. Code Programming OFF Code Programming OFF Eg, after a program code is received then ‘1 2 3”...
