NLS-HR200
Hand-held 2D Barcode Scanner
User Guide
Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NLS-HR200 and is the answer not in the manual?

Questions and answers

Related Manuals for Newland NLS-HR200

Summary of Contents for Newland NLS-HR200

  • Page 1 NLS-HR200 Hand-held 2D Barcode Scanner User Guide Version 1.0...
  • Page 2 Revisions Version Description Date Pre-release Initial release 26-08-2009 Version 1.0 Support as from HR200 firmware Version 3.06.007 and higher. 04-02-2010 nlscan.com Page 2...
  • Page 3 Newland Auto-ID. No right to copy a licensed program in whole or in part is granted except as permitted under copyright law or as hereinafter expressly provided. The user agrees to maintain Newland Auto-ID’s copyright notice on the licensed programs delivered hereunder, and to include the same on any authorized copies it makes in whole or in part.

  • Page 4: Table Of Contents

    请更换节标题 Content About this guide Introduction ..............................1 Chapter Description ............................. 1 Graphic Notations ............................1 Newland Auto-ID Support Center ....................... 2 Getting to Start Introduction ..............................3 Getting to know HR200 ..........................4 Unpacking ............................. 4 Outline ..............................4 Data Interface ............................
  • Page 5 Table of Contents RS232 Interface Introduction ..............................28 Serial Port ..............................29 Baud Rate ............................29 Parity Check ............................30 Hardware Auto Flow Control（only for HR200） ................. 30 Data Bits Transmitted ......................... 31 Stop Bits .............................. 31 USB Interface Introduction ..............................32 USB HID-KBW ............................
  • Page 6 Table of Contents EAN-8 ................................ 53 Load Factory Default .......................... 53 Enable/Disable UCC/EAN-8 ......................53 Check Digit ............................53 2 Digits Addenda Code ........................54 5 Digits Addenda Code ........................54 EAN-8 expand to EAN-13 ........................55 EAN-13 ..............................56 Load Factory Default ..........................
  • Page 7 Table of Contents Code 93 ..............................77 Load Factory Default .......................... 77 Enable /Disable Code 93 ........................77 Select Message Length ........................78 Check Digit ............................79 UCC/EAN-128 ............................80 Load Factory Default .......................... 80 Enable/Disable UCC/EAN-128 ......................80 GS1 Databar ............................... 81 Load Factory Default ..........................
  • Page 8 Table of Contents Forward/Positive Direction PDF 417 ....................102 Mirror Image Identifying ........................102 QR Code ..............................103 Load Factory Default ........................103 Enable/Disable QR Code ........................103 Select Message Length ........................104 QR Twin Code ..........................105 Aztec ................................ 106 Load Factory Default ........................
  • Page 9 Table of Contents Message Interception & Pack Introduction .............................. 129 Message Interception ..........................130 Programming 1D Intercept Option ....................131 Programming 2D Intercept Option ....................132 Message Pack ............................133 Introduction ............................133 Normal Pack ............................. 133 Batch Programming Introduction .............................. 134 How to build a batch command .......................

  • Page 10: About This Guide

    About this guide Introduction This User Guide provides installation and programming instructions for the NLS-HR200 (“HR200”) . Product specification and dimensions are also included. Chapter Description Getting to Start, explains the theory of operation and electrical interface of the HR200 bar code scanner. It also describes how to install it and its technical specifications.

  • Page 11: Newland Auto-Id Support Center

    About this guide Newland Auto-ID Support Center If you have a problem with your equipment, contact the Newland Support Center in your region. Before call- ing, have the model number, serial number, and several of your barcodes at hand. Call the support Center from a phone near the scanning equipment so that the service person can try to talk you through your problem.

  • Page 12: Getting To Start

    Getting to Start Introduction HR200 is a 1D & 2D barcode reader. Newland Auto-ID patented technology ensure HR200 fast image capture and accurate decoding. It provides the customer the best value. HR200 can be used as a hand-held reader or as hand-free reader in a stand. Ergonomically designed to provide comfortable and easy use.

  • Page 13: Getting To Know Hr200

    Getting to Start Getting to know HR200 Unpacking Unpack HR200 and accessories. Check with the packing list. Make sure that there is no damage or missing part(s). If any damage or missing parts, please keep the original package and contact your supplier for services.

  • Page 14: Data Interface

    Getting to Start Getting to know HR200 Data Interface Dismount hole Cable slot Pin 1 Pin 10 There are two types of HR200 with a different main board in it. HR200P’s main board has USB and PS/2 interfaces and HR200R’s has USB and RS232 interfaces. HR200R Interface Definition HR200P Interface Definition Function...

  • Page 15: Communication Ports

    Getting to Start Communication Ports HR200 must connect to a Host to operate. A Host can be PC, POS, or any intelligent terminal with at least one of the following communication ports: USB, RS232, or PS/2. 1、 USB port on Host： 2、...

  • Page 16: Connecting With Usb Cable

    Getting to Start Connecting with USB Cable 1、 Insert USB Cable (RJ45 male head) into HR200 cable slot; 2、 Insert USB Cable (USB male head) into Host’s (female) USB connector; NOTE: HR200 is a DataPipe device. You need to install the driver on the Host to communicate with HR200.

  • Page 17: Connecting With Rs232 Cable

    Getting to Start Connecting with RS232 Cable 1、 Insert RS232 cable (RJ 45 male head) into HR200 cable slot; 2、 Insert RS232 cable (RS232 male head) into Host’s (female) RS232 connector; 3、 Connect RS232 cable and the mains with power adapter; nlscan.com Page 8...

  • Page 18: Connecting With Ps/2 Cable

    Getting to Start Connecting with PS/2 Cable 1、 Insert PS/2 cable (RJ 45 male DIN) into HR200 cable slot; 2、 Insert PS/2 cable (PS/2 male DIN) into Host PS/2 female slot; 3、 If necessary, connect PS/2 cable and the mains with power adapter; 4、...

  • Page 19: Removal Of Communication Cable

    Getting to Start Removal of Communication Cable A Pin that fit the HR200 “dismount hole” is needed. A paper clip could be ideal. Stretch one end of the paper clip to fit the “Dismount Hole”. Follow the steps: 1、 For RS232 and PS/2 connections, unplug the power adaptor. 2、...

  • Page 20: On, Off, Idle, Restart

    Getting to Start ON, OFF, IDLE, RESTART Power On Connect HR200 and Host, HR200 will power on automatically and in "Idle" (ready to use) state (factory default). Power Off There are 4 ways to "Power OFF": Remove Cable Off HR200; »...

  • Page 21: Reading

    Getting to Start Getting to Start Reading 1、Ensure HR200, cables, and the Host are connected, then turn the unit Power ON 2、Press & hold Trigger. Illumination LED and Aiming LED cast an Illumination Pattern (red light) and an Aiming Pattern (blue light);...
  • Page 22 Getting to Start Reading Adjust Height 1、 Select reading mode “auto mode” or “continuous mode” when working in hands-free mode. 2、 Adjust the stand height for the optimum reading stance. nlscan.com Page 13...

  • Page 23: Depth Of Field

    Getting to Start Depth of Field Reading Stance is defined as the distance between the Imager front and an object (barcode). It effects image capturing area and image quality, and thus effects reading performance. 36° 63mm Code 39 (5 mil) 120mm 25mm Code 39 (10 mil)

  • Page 24: Specifications

    Getting to Start Specifications Performance Image Sensor CMOS Resoluing 752 * 480 RS232 / HID-KBW / USB DataPipe/ USB COM Port Emulation / Interface HID-POS/ PS2 PDF417, QR Code(Model 1/2), DataMatrix (ECC200, ECC000, 050, 080,100,140), Aztec, Maxicode, etc. Symbologies Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ISBN, Code 93, GS1 Databar, Code 11,etc Precision ≥...

  • Page 25: Programming The Engine

    Engine. QuickSet Programming QuickSet is a Windows based GUI program for Newland Auto-ID bar code readers. It displays decoded data and captured images. The engine with its circuit board can be easily configured through the interface of QuickSet.

  • Page 26: Programming Notation

    Programming the Engine Programming the Engine Programming Notation Tools Code Programming ON Code Programming OFF ** Code Programming OFF 【Pro CMD：0006000】 This is the notation to disable the Code Programming. There are 4 parts of a notation: 1、 The first part of the notation is the barcode for Code Programming 2、...

  • Page 27: Code Programming On/Off

    Programming the Engine Programming the Engine Code Programming On/Off Tools Code Programming ON Read the “Code Programming ON” barcode to activate “Code Program- ming” function. One or more Code Programming barcodes can be read to configure the Engine. If an option or feature needs additional parameters, such as digits, they can be found at the end of this chapter.

  • Page 28: Illumination

    Programming the Engine Programming the Engine Illumination Tools Code Programming ON Illumination LED lighting up barcodes are used to capture better images. There are 4 modes: “Illumination Wink”: LED keeps flashing when reading » Code Programming OFF “Illumination Keep ON”: LED keeps on when Power ON »...

  • Page 29: Aiming

    Programming the Engine Programming the Engine Aiming Tools Code Programming ON There are 3 modes: “Aim Wink”: LED keeps flashing when reading » “Aim Keep ON”: LED keeps on when Power ON » “Aim OFF”: LED is off all the time »...

  • Page 30: Beep

    Programming the Engine Programming the Engine Beep Tools Code Programming ON Decoding Beep Read “Beep ON” to enable all decoding beep denotation and read “Beep OFF” to disable. Code Programming OFF **Beep ON 【Pro CMD：0203010】 Beep OFF 【Pro CMD：0203000】 Decoding Beep Type **Type 1 【Pro CMD：0203020】...

  • Page 31: Decoding Beep Volume

    Programming the Engine Programming the Engine Beep Tools Code Programming ON Decoding Beep Volume ** Loud Code Programming OFF 【Pro CMD：0203030】 【Pro CMD：0203032】 Medium 【Pro CMD：0203031】 Power On Beep ** Beep On 【Pro CMD：0204001】 Beep OFF 【Pro CMD：0204000】 Beep Denotation (Beeper Definitions) Beep Denotation low-higher-higher-higher...

  • Page 32: Reading Mode

    Programming the Engine Programming the Engine Reading Mode Tools Code Programming ON Hand-held Mode: Pull and keep holding the trigger line to read. Com- » plete one reading or release the trigger to terminate reading status. Auto Mode: The ambient luminance change in front of the engine auto- »...

  • Page 33: Reading Timeout And Delay

    Programming the Engine Programming the Engine Reading Timeout and Delay Tools Code Programming ON One Reading Timeout：If the engine doesn't read any barcode during the timeout period, it will stop reading automatically. One Reading Timeout is valid in Auto mode. The default timeout is 3000ms. Same Barcode Reading Delay：It is used to avoid misreading on the same Code Programming OFF barcode (the same format and message) in a Same Barcode Reading Delay...

  • Page 34: Sensitivity

    Programming the Engine Programming the Engine Sensitivity Tools Code Programming ON Sensitivity is how sensitive the engine is to ambient illumination change. » Sensitivity value is [1 .. 20] » The lower the sensitivity value is the higher sensitivity will be. The low- »...

  • Page 35: Default

    Programming the Engine Programming the Engine Default Tools Code Programming ON Factory Default Read “Load All Factory Default” to reset all parameters to factory default. Applicable conditions: Code Programming OFF User options programming wrong configuration leads to reading mal- » function Forget details of previous programming and start over.

  • Page 36: Query Product Information

    Programming the Engine Programming the Engine Query Product Information Tools Code Programming ON Product information could be obtained by reading "Query Product Information" barcode. The engine will send it to the Host immediately. “Power ON, Send Product Info”, the engine sends product information through serial port(only) to the Host after Power ON.

  • Page 37: Rs232 Interface

    RS232 Interface Introduction Under RS232 connection, the engine and the Host use the same communication parameters: baud rate, parity check, data bits select and stop bits select. Enable RS232 Connection 【Pro CMD：1100000】 nlscan.com Page 28...

  • Page 38: Serial Port

    RS232 Interface RS232 Interface Serial Port Tools Code Programming ON The engine and the Host should use the same serial port parameters: baud rate, parity check, data bits and stop bits. The sequence is as follows: 9600 (baud rate), null (parity check), 8 (data bits), 1 (stop bits). Baud Rate Code Programming OFF Baud rate is the number of bits of data transmitted per second.

  • Page 39: Parity Check

    RS232 Interface RS232 Interface Serial Port Tools Code Programming ON Parity Check Parity check options should be the same on the engine and the Host. Select Odd parity: If data has an odd number of 1 bits, the parity bit »...

  • Page 40: Data Bits Transmitted

    RS232 Interface RS232 Interface Serial Port Tools Code Programming ON Data Bits Transmitted Select data bits transmitted to be 5, 6, 7 and 8. Ensure the selections on the engine and the Host are the same. Code Programming OFF ** 8 Data Bits 【Pro CMD：0103030】...

  • Page 41: Usb Interface

    When using a USB connection, the default protocol is USB DataPipe. USB DataPipe is a Newland Auto-ID Co., Ltd. developed protocol. The DataPipe driver should be installed on the Host. It supports data transmission and user preference programming. QuickSet works with DataPipe.

  • Page 42: Usb Hid-Kbw

    USB Interface USB Interface USB HID-KBW Tools Code Programming ON USB connection (no driver needed) supports simulating the Imager transmission to be a USB keyboard input. The Host receives keystrokes of the virtual keyboard. It works in “Plug and Play” base. There is no driver required. Code Programming OFF Select USB HID-KBW 【Pro CMD：1100020】...

  • Page 43: Usb Country Keyboard Types

    USB Interface USB Interface USB HID-KBW Tools Code Programming ON USB Country Keyboard Types » The keyboard arrangements and country codes vary in different countries. Refer country codes to the table “USB Country Keyboard Types”. Follow the steps mentioned below to program. Code Programming OFF »...

  • Page 44: Usb Country Keyboard Types

    USB Interface USB HID-KBW USB Country Keyboard Types Country/Language Number Country/Language Number U.S. Netherlands(Dutch) Belgium Norway Brazil Poland Canada(French) Portugal Czechoslovakia Romania Denmark Russia Finland(Swedish) Slovakia France Spain Germany/Austria Sweden Greece Switzerland(German) Hungary Turkey F Israel(Hebrew) Turkey Q Italy Latin-American Japan nlscan.com Page 35...

  • Page 45: Unknown Characters, Beep

    USB Interface USB Interface USB HID-KBW Tools Code Programming ON Unknown Characters, Beep HID-KBW deems an unknown character to be a character is not included in a country keyboard type. It may not be able to allocate and send a keystroke, thus lead to an error beep.

  • Page 46: Emulate Alt + Keypad

    USB Interface USB Interface USB HID-KBW Tools Code Programming ON Emulate ALT + keypad When enabled, full ASCII characters (0x00～0xff) can be sent over the numeric keypad regardless country keyboard selections. 1、 “ALT” Make Code Programming OFF 2、 According to the ASCII value, input the numbers over the numeric keypad 3、...

  • Page 47: Function Key Mapping

    USB Interface USB Interface USB HID-KBW Tools Code Programming ON Function Key Mapping When enabled, function characters (0x00~0x1F) are sent as ASCII sequences over the numeric keypad. 1、 “Ctrl make” Code Programming OFF 2、 Hit function key 3、 “Ctrl Break” ** No Function Key Mapping 【Pro CMD：1103130】...

  • Page 48: Ascii Function Key Mapping Table

    USB Interface USB HID-KBW ASCII Function Key Mapping Table ASCII(HEX) Function key ASCII(HEX) Function Key nlscan.com Page 39...

  • Page 49: Keystroke Delay

    USB Interface USB Interface USB HID-KBW Tools Code Programming ON Keystroke Delay This parameter sets the delay, in milliseconds, between emulated keystrokes. Scan programming code below to increase the delay when the Host require a slower trans- mission of data. Code Programming OFF ** No Delay 【Pro CMD：1103050】...

  • Page 50: Convert Case

    USB Interface USB Interface USB HID-KBW Tools Code Programming ON Convert Case The Imager converts all barcode messages to the selected case. Code Programming OFF ** No Case Conversion 【Pro CMD：1103040】 Convert All to Upper Case 【Pro CMD：1103041】 Convert All to Lower Case 【Pro CMD：1103042】...

  • Page 51: Emulate Numeric Keypad

    USB Interface USB Interface USB HID-KBW Tools Code Programming ON Emulate Numeric Keypad Code Programming OFF When disable, the whole barcode message will be emulated as keystrokes on main keyboard. Read “Emulate Numeric Keypad” to enable the function. when “0~9”is of the barcode message, it will be emulated as keystrokes on numeric keypad.

  • Page 52: Usb Datapipe

    USB DataPipe Tools Code Programming ON This protocol is defined by Newland Auto-ID. A driver has to be installed before using this protocol to communicate with reader, The advantage of using this protocol is the fast data transmission. Meanwhile, the SDK can be easily integrated into the application system.

  • Page 53: Usb Com Port Emulation

    USB Interface USB Interface USB COM Port Emulation Tools Code Programming ON When the USB port is connected to Host serial port in order to receive data from scanner, the model of imitating USB-to-RS232 has to be chosen. Hence, the engine and the Host must communicate at the same parameters and the parameters of real serial port and visual serial port must be the same.

  • Page 54: Hid-Pos

    USB Interface USB Interface HID-POS Tools Code Programming ON Introduction The HID POS interface is recommended for new applications. It can send up to 56 characters in a single USB report and is muchfaster than keyboard emulation. Features: » Code Programming OFF HID based, no custom driver required »...

  • Page 55: Access The Device In Your Program

    USB Implementers Forum. The Newland vendor ID (VID) is 1EAB (hex). The second is the PID (Product ID). A range of PIDs is used for each Newland product sub family, so each PID contains a base number and an interface type (keyboard, COM port, etc.).

  • Page 56: Ps/2 Interface

    PS/2 Interface Introduction PS/2 connection is emulated as an HID-KBW input. It can only transmit data to the Host, and does not support programming commands from the Host. It does not support hot plug. Connecting P/S 2 Plugging while the unit is on will cause permanent damage. Select PS/2 【Pro CMD：1100070】...

  • Page 57: Symbols

    Symbols Introduction This chapter lists all the available symbols and provides the programming barcodes to enable/disable them. Disabling reading of the symbols which do not apply, will improve reading performance. The few abling reading of the symbols are, the fast the engine will work. nlscan.com Page 48...

  • Page 58: General Options

    Symbols General Options Tools Code Programming ON Disable Reading All Disable Reading All = Allow reading Programming Codes only. Code Programming OFF Disable Reading All 【Pro CMD：0001010】 Enable Reading All Enable Reading All = Enable to read all symbols and Programming Codes. Enable Reading All 【Pro CMD：0001020】...

  • Page 59: Enable Reading All 2D

    Symbols General Options Tools Code Programming ON Enable Reading All 2D Code Programming OFF Enable Reading All 2D 【Pro CMD：0001060】 Disable Reading All 2D Disable Reading All 2D 【Pro CMD：0001050】 nlscan.com Page 50...

  • Page 60: Code 128

    Symbols Code 128 Tools Code Programming ON Load Factory Default Code Programming OFF ** Load Code 128 Factory Default 【Pro CMD：0400000】 Enable/Disable Code 128 Disable Code 128 【Pro CMD：0400010】 ** Enable Code 128 【Pro CMD：0400020】 When the engine can not read Code 128, please read“Enable Code 128” and try again. nlscan.com Page 51...

  • Page 61: Select Message Length

    Symbols Code 128 Tools Code Programming ON Select Message Length It is used to program the valid reading length of Code 128. The engine will not send barcode message to the Host, if the decoded data length does not match the valid length. Code 128 Message Length is defined by “Min.

  • Page 62: Load Factory Default

    Symbols EAN-8 Tools Code Programming ON Load Factory Default Code Programming OFF ** Load UCC/EAN-8 Factory Default 【Pro CMD：0401000】 Enable/Disable UCC/EAN-8 ** Enable UCC/EAN-8 【Pro CMD：0401020】 Disable UCC/EAN-8 【Pro CMD：0401010】 Check Digit UCC/EAN-8 is fixed 8 digits barcode and the last digit is check digit. **Transmit Check 【Pro CMD：0401040】...

  • Page 63: Digits Addenda Code

    Symbols EAN-8 Tools Code Programming ON 2 Digits Addenda Code Addenda Code is the one to the right of an ordinary code. Picture below shows an ordinary code with a 2 digits Addenda Code. The left one in blue lines is an ordinary code. The right one in red lines is the 2 digits Addenda Code.

  • Page 64: Expand To Ean-13

    Symbols EAN-8 Tools Code Programming ON EAN-8 expand to EAN-13 Expand EAN-8 to EAN-13, by adding 5 bytes of “0” to the left, and then transmit. Code Programming OFF ** Do Not Expand to EAN-13 【Pro CMD：0401090】 Expand to EAN-13 【Pro CMD：0401100】...

  • Page 65: Load Factory Default

    Symbols EAN-13 Tools Code Programming ON Load Factory Default ** Load EAN-13 Factory Default 【Pro CMD：0402000】 Code Programming OFF Disable/EnableEAN-13 ** Enable EAN-13 【Pro CMD：0402020】 Disable EAN-13 【Pro CMD：0402010】 Check Digit ** Transmit Check 【Pro CMD：0402040】 Do Not Transmit Check 【Pro CMD：0402030】...

  • Page 66: Digits Addenda Code

    Symbols EAN-13 Tools Code Programming ON 2 Digits Addenda Code Addenda Code is the one to the right of an ordinary code. Picture below shows an ordinary code with a 2 digits Addenda Code. The left one in blue lines is an ordinary code. The right one in red lines is the 2 digits Addenda Code.

  • Page 67: Upc-E

    Symbols UPC-E Tools Code Programming ON Load Factory Default ** Load UPC-E Factory Default 【Pro CMD：0403000】 Code Programming OFF Disable/Enable UPC-E ** Enable UPC-E 【Pro CMD：0403020】 Disable UPC-E 【Pro CMD：0403010】 When the engine can not read UPC-E, please read “Enable UPC-E” and try again. Check Digit UPC-E is fixed 8 digits barcode and the last digit is check digit.

  • Page 68: Digits Addenda Code

    Symbols UPC-E Tools Code Programming ON 2 Digits Addenda Code Addenda Code is the one to the right of an ordinary code. Picture below shows an ordinary code with a 2 digits Addenda Code. The left one in blue lines is an ordinary code. The right one in red lines is the 2 digits Addenda Code.

  • Page 69: Transmit Default "0

    Symbols UPC-E Tools Code Programming ON Transmit Default “0” The first byte of UPC-E is default to “0”. Code Programming OFF ** Do Not Transmit “0” 【Pro CMD：0403090】 Transmit “0” 【Pro CMD：0403100】 UPC-E Expand to UPC-A Follow the standard algorithm to expand UPC-E to UPC-A. **Do Not Expand to UPC-A 【Pro CMD：0403110】...

  • Page 70: Upc-A

    Symbols UPC-A Tools Code Programming ON Load Factory Default ** Load UPC-A Factory Default 【Pro CMD：0404000】 Code Programming OFF Disable/Enable UPC-A ** Enable UPC-A 【Pro CMD：0404020】 Disable UPC-A 【Pro CMD：0404010】 When the engine can not read UPC-A, please read “Enable UPC-A” and try again. Check Digit UPC-A is fixed 13 digits barcode and the last digit is Check Digit.

  • Page 71: Digits Addenda Code

    Symbols UPC-A Tools Code Programming ON 2 Digits Addenda Code Addenda Code is the one to the right of an ordinary code. Picture below shows an ordinary code with a 2 digits Addenda Code. The left one in blue lines is an ordinary code. The right one in red lines is the 2 digits Addenda Code.

  • Page 72: Transmit Default "0

    Symbols UPC-A Tools Code Programming ON Transmit Default “0” The first byte of UPC-A is default to “0”. Code Programming OFF **Do Not Transmit “0” 【Pro CMD：0404090】 Transmit “0” 【Pro CMD：0404100】 UPC-A has the default “0” but it is not printed out, unlike UPC-E. Read “Transmit 0”...

  • Page 73: Interleaved 2 Of 5

    Symbols Interleaved 2 of 5 Tools Code Programming ON Load Factory Default Code Programming OFF ** Load Interleaved 2 of 5 Factory Default 【Pro CMD：0405000】 Disable/Enable Interleaved 2 of 5 ** Enable Interleaved 2 of 5 【Pro CMD：0405020】 Disable Interleaved 2 of 5 【Pro CMD：0405010】...

  • Page 74: Select Message Length

    Symbols Interleaved 2 of 5 Tools Code Programming ON Select Message Length It is used to program the valid reading length of Interleaved 2 of 5. The engine will not send barcode message to the Host, if the decoded data length does not match the valid length.

  • Page 75: Check Digit

    Symbols Interleaved 2 of 5 Tools Code Programming ON Check Digit Interleaved 2 of 5 may include Check Digit (not compulsory) following its barcode messages. It verifies the barcode message. “NO Check, Transmit All” means to read without check and transmit »...

  • Page 76: Specified Lengths

    Symbols Interleaved 2 of 5 Tools Code Programming ON Specified Lengths Program the engine to read specified lengths or ranges of specified lengths for Interleaved 2 of 5. The length value must be 3 decimal digits. And the length value MUST be an even number between 2 to 64. Read “Enable Specified Length”...

  • Page 77: Itf-14

    Symbols ITF-14 Tools Code Programming ON ITF-14 is a fixed length, 14 bytes Interleaved 2 of 5 barcode with Check digit. By factory default, it is disabled. When enabled, ITF-14 precedes 14-byte Interleaved 2 of 5 barcode. Code Programming OFF **Disable ITF-14 【Pro CMD：0405080】...

  • Page 78: Itf-6

    Symbols ITF-6 Tools Code Programming ON ITF-6 is a fixed length 6 bytes Interleaved 2 of 5 barcode with check digit. When enabled, ITF-6 precedes 6-byte Interleaved 2 of 5 barcode. Code Programming OFF **Disable ITF-6 User Selection 【Pro CMD：0405110】 ITF-6, Read, Do Not Transmit Check Digit 【Pro CMD：0405120】...

  • Page 79: Code 39

    Symbols Code 39 Tools Code Programming ON Load Factory Default Code Programming OFF ** Load Code 39 Factory Default 【Pro CMD：0408000】 Enable/Disable Code 39 ** Enable Code 39 【Pro CMD：0408020】 Disable Code 39 【Pro CMD：0408010】 When the engine can not read Code 39, please read “Enable Code 39” and try again Transmit Start &...

  • Page 80: Select Message Length

    Symbols Code 39 Tools Code Programming ON Select Message Length It is used to program the valid reading length of Code 39. The engine will not send barcode message to the Host, if the decoded data length does not match the valid length.

  • Page 81: Check Digit

    Symbols Code 39 Tools Code Programming ON Check Digit Code 39 may include Check Digit (not compulsory) following its barcode message. It verifies the barcode message. "NO Check, Transmit All" means to read without check and transmit » all bytes including barcode message and Check Digit. Code Programming OFF "Check, Do Not Transmit Check Digit"...

  • Page 82: Codabar

    Symbols Codabar Tools Code Programming ON Load Factory Default Code Programming OFF ** Load Codabar Factory Default 【Pro CMD：0409000】 Enable/Disable Codabar ** Enable Codabar 【Pro CMD：0409020】 Disable Codabar 【Pro CMD：0409010】 When the engine can not read Codabar, please read “Enable Codabar” and try again. nlscan.com Page 73...

  • Page 83: Select Message Length

    Symbols Codabar Tools Code Programming ON Select Message Length It is used to program the valid reading length of Codabar. The engine will not send barcode message to the Host, if the decoded data length does not match the valid length. Code Programming OFF Codabar Message Length is defined by “Min.

  • Page 84: Check Digit

    Symbols Codabar Tools Code Programming ON Check Digit Codabar may include Check Digit (not compulsory) following its barcode message. It verifies the barcode message. "NO Check, Transmit All" means to read without check and transmit » all bytes including barcode message and Check Digit. Code Programming OFF "Check, Do Not Transmit Check Digit"...

  • Page 85: Transmit Start & Stop Character

    Symbols Codabar Tools Code Programming ON Transmit Start & Stop Character Codabar uses either one of “A”, “B”, “C” and “D” as the start character and the stop character. Transmission of them can be selected. Code Programming OFF **Transmit Both Start & Stop Character 【Pro CMD：0409090】...

  • Page 86: Code 93

    Symbols Code 93 Tools Code Programming ON Load Factory Default Code Programming OFF ** Load Code 93 Factory Default 【Pro CMD：0410000】 Enable /Disable Code 93 ** Disable Code 93 【Pro CMD：0410010】 Enable Code 93 【Pro CMD：0410020】 When the engine can not read Code 93, please read “Enable Code 93” and try again. nlscan.com Page 77...

  • Page 87: Select Message Length

    Symbols Code 93 Tools Code Programming ON Select Message Length It is used to program the valid reading length of Code 93. The engine will not send barcode message to the Host, if the decoded data length does not match the valid length.

  • Page 88: Check Digit

    Symbols Code 93 Tools Code Programming ON Check Digit Code 93 may include Check Digits (not compulsory) following its barcode message. The two digits verify the barcode message. "NO Check, Transmit All" means to read without check and transmit » all bytes including barcode message and Check Digits.

  • Page 89: Ucc/Ean-128

    Symbols UCC/EAN-128 Tools Code Programming ON Load Factory Default ** Load UCC/EAN-128 Factory Default 【Pro CMD：0412000】 Code Programming OFF Enable/Disable UCC/EAN-128 ** Enable UCC/EAN-128 【Pro CMD：0412020】 Disable UCC/EAN-128 【Pro CMD：0412010】 When the engine can not read UCC/EAN-128, please read “Enable UCC/EAN-128” and try again.

  • Page 90: Gs1 Databar

    Symbols GS1 Databar Tools Code Programming ON Load Factory Default Code Programming OFF ** Load GS1 Databar Factory Default 【Pro CMD：0413000】 Enable/Disable GS1 Databar ** Enable GS1 Databar 【Pro CMD：0413020】 Disable GS1 Databar 【Pro CMD：0413010】 When the engine can not read GS1 Databar, please read “Enable GS1 Databar” and try again.

  • Page 91: Ean·ucc Composite

    Symbols EAN·UCC Composite Tools Code Programming ON Load Factory Default Code Programming OFF ** Load EAN·UCC Composite Factory Default 【Pro CMD：0414000】 Enable/Disable EAN·UCC Composite Enable EAN·UCC Composite 【Pro CMD：0414020】 ** Disable EAN·UCC Composite 【Pro CMD：0414010】 Enable UPC/EAN Composite 【Pro CMD：0414040】 ** Disable UPC/EAN Composite 【Pro CMD：0414030】...

  • Page 92: Code 11

    Symbols Code 11 Tools Code Programming ON Load Factory Default Code Programming OFF ** Load Code 11 Factory Default 【Pro CMD：0415000】 Enable/Disable Code 11 Enable Code 11 【Pro CMD：0415020】 ** Disable Code 11 【Pro CMD：0415010】 When the engine can not read Code 11, please read “Enable Code 11” and try again. nlscan.com Page 83...

  • Page 93: Select Message Length

    Symbols Code 11 Tools Code Programming ON Select Message Length It is used to program the valid reading length of Code 11. The engine will not send barcode message to the Host, if the decoded data length does not match the valid length.

  • Page 94: Check Digit

    Symbols Code 11 Tools Code Programming ON Check Digit Code 11 may include Check Digit (not compulsory) following its barcode message. It verifies the barcode message. "NO Check, Transmit All" means to read without check and transmit all » bytes including barcode message and Check Digit. Code Programming OFF "Check, Do Not Transmit Check Digit"...

  • Page 95: Isbn

    Symbols ISBN Tools Code Programming ON Load Factory Default Code Programming OFF ** Load ISBN Factory Default 【Pro CMD：0416000】 Enable/Disable ISBN Enable ISBN 【Pro CMD：0416020】 ** Disable ISBN 【Pro CMD：0416010】 When the engine can not read ISBN, please read “Enable ISBN” and try again. Transmit ** Transmit 13 digits 【Pro CMD：0416030】...

  • Page 96: Industrial 25

    Symbols Industrial 25 Tools Code Programming ON Load Factory Default Code Programming OFF ** Load Industrial 25 Factory Default 【Pro CMD：0417000】 Enable/Disable Industrial 25 Enable Industrial 25 【Pro CMD：0417020】 ** Disable Industrial 25 【Pro CMD：0417010】 When the engine can not read Industrial 25, please read “Enable Industrial 25” and try again.

  • Page 97: Select Message Length

    Symbols Industrial 25 Tools Code Programming ON Select Message Length It is used to program the valid reading length of Industrial 25. The engine will not send barcode message to the Host, if the decoded data length does not match the valid length. Industrial 25 Message Length is defined by “Min.

  • Page 98: Check Digit

    Symbols Industrial 25 Tools Code Programming ON Check Digit Industrial 25 may include Check Digit (not compulsory) following its barcode message. It verifies the barcode message. "NO Check, Transmit All" means to read without check and transmit all » bytes including barcode message and Check Digit. Code Programming OFF "Check, Do Not Transmit Check Digit"...

  • Page 99: Standard 25

    Symbols Standard 25 Tools Code Programming ON Load Factory Default Code Programming OFF ** Load Standard 25 Factory Default Pro CMD 【 ：0418000】 Enable/Disable Standard 25 Enable Standard 25 【Pro CMD：0418020】 ** Disable Standard 25 【Pro CMD：0418010】 When the engine can not read Standard 25, please read “Enable Standard 25” and try again.

  • Page 100: Select Message Length

    Symbols Standard 25 Tools Code Programming ON Select Message Length It is used to program the valid reading length of Standard 25. The engine will not send barcode message to the Host, if the decoded data length does not match the valid length. Standard 25 Message Length is defined by “Min.

  • Page 101: Check Digit

    Symbols Standard 25 Tools Code Programming ON Check Digit Standard 25 may include Check Digit (not compulsory) following its barcode message. It verifies the barcode message. "NO Check, Transmit All" means to read without check and transmit all » bytes including barcode message and Check Digit. Code Programming OFF "Check, Do Not Transmit Check Digit"...

  • Page 102: Plessey

    Symbols Plessey Tools Code Programming ON Load Factory Default Code Programming OFF ** Load Plessey Factory Default Pro CMD 【 ：0419000】 Enable/Disable Plessey Enable Plessey 【Pro CMD：0419020】 ** Disable Plessey 【Pro CMD：0419010】 When the engine can not read Plessey, please read “Enable Plessey” and try again. nlscan.com Page 93...

  • Page 103: Select Message Length

    Symbols Plessey Tools Code Programming ON Select Message Length It is used to program the valid reading length of Plessey. The engine will not send barcode message to the Host, if the decoded data length does not match the valid length. Plessey Message Length is defined by “Min.

  • Page 104: Check Digit

    Symbols Plessey Tools Code Programming ON Check Digit Plessey may include Check Digits (not compulsory) following its barcode message. The two digits verify the barcode message. "NO Check, Transmit All" means to read without check and transmit all » bytes including barcode message and Check Digits. Code Programming OFF "Check, Do Not Transmit Check Digit"...

  • Page 105: Msi-Plessey

    Symbols MSI-Plessey Tools Code Programming ON Load Factory Default Code Programming OFF ** Load MSI-Plessey Factory Default Pro CMD 【 ：0420000】 Enable/Disable MSI-Plessey Enable MSI-Plessey 【Pro CMD：0420020】 ** Disable MSI-Plessey 【Pro CMD：0420010】 When the engine can not read MSI-Plessey, please read “Enable MSI-Plessey” and try again.

  • Page 106: Select Message Length

    Symbols MSI-Plessey Tools Code Programming ON Select Message Length It is used to program the valid reading length of MSI-Plessey. The engine will not send barcode message to the Host, if the decoded data length does not match the valid length. Code Programming OFF MSI-Plessey Message Length is defined by “Min.

  • Page 107: Check Digit

    Symbols MSI-Plessey Tools Code Programming ON Check Digit Plessey may include Check Digits(s) (not compulsory) following its barcode message. It may have one or two digits, which verify the barcode message. "NO Check, Transmit All" means to read without check and transmit all »...

  • Page 108: Pdf417

    Symbols PDF417 Tools Code Programming ON Load Factory Default Code Programming OFF ** Load PDF417 Factory 【Pro CMD：0501000】 Enable/Disable PDF417 ** Enable PDF417 【Pro CMD：0501020】 Disable PDF417 【Pro CMD：0501010】 When the engine can not read PDF417, please read “Enable PDF417” and try again. nlscan.com Page 99...

  • Page 109: Select Message Length

    Symbols PDF417 Tools Code Programming ON Select Message Length It is used to program the valid reading length of PDF417. The engine will not send barcode message to the Host, if the decoded data length does not match the valid reading length.

  • Page 110: Pdf417 Twin Code

    Symbols PDF417 Tools Code Programming ON PDF417 Twin Code PDF417 twin code is 2 PDF417 barcodes paralleled vertically or horizontally. They must have the same direction. Their specifications must be similar and the distance between them must be short. There are 3 options for reading PDF417 twin code: Code Programming OFF Single PDF417 Only: Read either PDF417 code.

  • Page 111: Forward/Positive Direction Pdf 417

    Symbols PDF417 Tools Code Programming ON Forward/Positive Direction PDF 417 PDF 417 has forward or positive direction. Forward Direction Barcode：Light colour ground, Deep colour bars. Positive Direction Barcode：Deep colour ground, Light colour bars. Code Programming OFF ** Forward Direction Barcode Only 【Pro CMD：0501320】...

  • Page 112: Qr Code

    Symbols QR Code Tools Code Programming ON Load Factory Default Code Programming OFF ** Load QR Code Factory Default 【Pro CMD：0502000】 Enable/Disable QR Code ** Enable QR Code 【Pro CMD：0502020】 Disable QR Code 【Pro CMD：0502010】 When the engine can not read QR Code, please read “Enable QR Code” and try again. nlscan.com Page 103...

  • Page 113: Select Message Length

    Symbols QR Code Tools Code Programming ON Select Message Length It is used to program the valid reading length of QR Code. The engine will not send barcode message to the Host, if the decoded data length does not match the valid length.

  • Page 114: Qr Twin Code

    Symbols QR Code Tools Code Programming ON QR Twin Code QR twin code is 2 QR barcodes paralleled vertically or horizontally.They must have the same direction. Their specifications must be similar and the distance between them must be short. There are 3 options for reading QR twin code: Code Programming OFF Single QR Only: Read either QR code.

  • Page 115: Aztec

    Symbols Aztec Tools Code Programming ON Load Factory Default Code Programming OFF ** Load Aztec Factory Default 【Pro CMD：0503000】 Enable/Disable Aztec Enable Aztec 【Pro CMD：0503020】 ** Disable Aztec 【Pro CMD：0503010】 When the engine can not read Aztec, please read “Enable Aztec” and try again. nlscan.com Page 106...

  • Page 116: Select Message Length

    Symbols Aztec Tools Code Programming ON Select Message Length It is used to program the valid reading length of Aztec. The engine will not send barcode message to the Host, if the decoded data length does not match the valid length.

  • Page 117: Reading Multi-Barcodes Of An Image

    Symbols Aztec Tools Code Programming ON Reading Multi-barcodes of an Image There are three modes: Mode 1：Read one barcode only. » Code Programming OFF Mode 2：Read fixed number of barcodes only. » Mode 3：Composite Reading. Read fixed number of barcodes first, if failed, »...

  • Page 118: The Number Of Multi-Barcodes

    Symbols Aztec Tools Code Programming ON The number of Multi-barcodes Code Programming OFF ** 1 【Pro CMD：0503060】 【Pro CMD：0503064】 【Pro CMD：0503061】 【Pro CMD：0503065】 【Pro CMD：0503062】 【Pro CMD：0503066】 【Pro CMD：0503063】 【Pro CMD：0503067】 nlscan.com Page 109...

  • Page 119: Data Matrix

    Symbols Data Matrix Tools Code Programming ON Load Factory Default Code Programming OFF ** Load Data Matrix Factory Default 【Pro CMD：0504000】 Enable/Disable Data Matrix ** Enable Data Matrix 【Pro CMD：0504020】 Disable Data Matrix 【Pro CMD：0504010】 When the engine can not read Data Matrix, please read “Enable Data Matrix” and try again.

  • Page 120: Select Message Length

    Symbols Data Matrix Tools Code Programming ON Select Message Length It is used to program the valid reading length of Data Matrix. The engine will not send barcode message to the Host, if the decoded data length does not match the valid reading length.

  • Page 121: Data Matrix Twin Code

    Symbols Data Matrix Tools Code Programming ON Data Matrix Twin Code Data Matrix twin code is 2 Data Matrix barcodes paralleled vertically or horizontally.They must have the same direction. Their specifications must be similar and the distance between them must be short. Code Programming OFF There are 3 options for reading Data Matrix: Single Data Matrix Only: Read either Data Matrix.

  • Page 122: Rectangular Symbols

    Symbols Data Matrix Tools Code Programming ON Rectangular Symbols Data Matrix has two formats: Square symbols, which has the same amount of models in length and » Code Programming OFF width： 10*10，12*12..144*144。 Rectangular symbols, which has different amounts of models in length and »...

  • Page 123: Forward/Positive Direction Data Matrix

    Symbols Data Matrix Tools Code Programming ON Forward/Positive Direction Data Matrix Data Matrix has forward or positive direction. Forward Direction Barcode：Light colour ground, Deep colour bars. Positive Direction Barcode：Deep colour ground, Light colour bars. Code Programming OFF ** Forward Direction Barcode Only 【Pro CMD：0504320】...

  • Page 124: Maxicode

    Symbols Maxicode Tools Code Programming ON Load Factory Default Code Programming OFF ** Load Maxicode Factory Default 【Pro CMD：0505000】 Enable/Disable Maxicode Enable Maxicode 【Pro CMD：0505020】 ** Disable Maxicode 【Pro CMD：0505010】 When the engine can not read Maxicode, please read “Enable Maxicode” and try again. nlscan.com Page 115...

  • Page 125: Select Message Length

    Symbols Maxicode Tools Code Programming ON Select Message Length It is used to program the valid reading length of Maxicode. The engine will not send barcode message to the Host, if the decoded data length does not match the valid reading length.

  • Page 126: Ocr

    Introduction OCR (Optical Character Recognition) is the technology that captures image of printed information, and recognizes the image to editable characters. The engine supports OCR B standard and specific typefaces, such as: ■ 0 1 2 3 4 5 6 7 8 ■...

  • Page 127: Prefix/Suffix

    Prefix/Suffix Introduction 1D barcodes could contain digits, letters and symbols, etc. 2D barcodes could contain more data, such as Chinese characters and other multi-byte characters. However, in reality, they do not and should not have all the information we need, such as barcode type, date and time of scan, delimiter, and so on, in order to keep the code short and flexible.

  • Page 128: General Programming

    Prefix/Suffix Prefix/Suffix General Programming Tools Code Programming ON Disable or Enable Prefix/Suffix Disable All Prefix/Suffix: Transmit barcode message with no Prefix/Suffix. Enable All Prefix/Suffix: Allow appending Code ID prefix, AIM prefix, User Code Programming OFF prefix, User suffix and Stop suffix to the barcode message. ** Disable All Prefix/Suffix 【Pro CMD：0311000】...

  • Page 129: Prefix Sequences

    Prefix/Suffix Prefix/Suffix General Programming Tools Code Programming ON Prefix Sequences 6 options of Prefix Sequences: Code Programming OFF ** CodeID + AIM + User Prefix 【Pro CMD：0317000】 AIM + User Prefix + CodeID 【Pro CMD：0317030】 CodeID + User Prefix + AIM 【Pro CMD：0317010】...

  • Page 130: Disable Or Enable User Prefix

    Prefix/Suffix Prefix/Suffix General Programming Tools Code Programming ON Disable or Enable User Prefix User Prefix is added before barcode message. For example, if the user prefix is “AB” and the barcode message is “123”, the Host receives “AB123”. Code Programming OFF ** Disable User Prefix 【Pro CMD：0305000】...

  • Page 131: Aim Prefix

    Prefix/Suffix Prefix/Suffix AIM Prefix Tools Code Programming ON AIM (Automatic Identification Manufactures) defines AIM prefix for many standard barcode formats. AIM Prefix Format: “]” + AIM prefix + “0” Code Programming OFF ** Disable AIM Prefix 【Pro CMD：0308000】 Enable AIM Prefix 【Pro CMD：0308030】...

  • Page 132: Code Id Prefix

    Prefix/Suffix Prefix/Suffix Code ID Prefix Tools Code Programming ON Besides AIM prefix, Code ID prefix can be used to denote barcode format and can be customized. The Code ID prefix MUST be one (1) or two (2) visible English letters. Code Programming OFF ** No Code ID Prefix 【Pro CMD：0307000】...

  • Page 133: Modify Code Id

    Prefix/Suffix Prefix/Suffix Code ID Prefix Tools Code Programming ON Modify Code ID See the examples below for how to modify a code ID and restore factory default code ID. Modify PDF417 Code ID to be “p” (hex value is 0x70) Code Programming OFF 1.
  • Page 134 Prefix/Suffix Prefix/Suffix Code ID Prefix Tools Code Programming ON Modify EAN-8 【Pro CMD：0004040】 Code Programming OFF Modify EAN-13 【Pro CMD：0004050】 Modify ITF-6 【Pro CMD：0004100】 Modify UPC-E 【Pro CMD：0004060】 Modify Code 39 【Pro CMD：0004130】 Modify UPC-A 【Pro CMD：0004070】 Modify Codabar 【Pro CMD：0004150】 Modify Interleaved 2 of 5 【Pro CMD：0004080】...
  • Page 135 Prefix/Suffix Prefix/Suffix Code ID Prefix Tools Code Programming ON Modify Code 128 【Pro CMD：0004020】 Code Programming OFF Modify ISBN 【Pro CMD：0004240】 Modify UCC/EAN-128 【Pro CMD：0004030】 Modify Industrial 25 【Pro CMD：0004250】 Modify Code 11 【Pro CMD：0004280】 Modify Standard 25 【Pro CMD：0004260】 Modify EAN•UCC Composite 【Pro CMD：0004300】...

  • Page 136: User Suffix

    Prefix/Suffix Prefix/Suffix User Suffix Tools Code Programming ON Disable or Enable User Suffix User suffix is appended to the right of barcode message. For example, if user suffix is “AB”, and the barcode message is “123”, The Host receives “123AB”. Code Programming OFF **Disable User Suffix 【Pro CMD：0306000】...

  • Page 137: Stop Suffix

    Prefix/Suffix Prefix/Suffix Stop Suffix Tools Code Programming ON Disable or Enable Stop Suffix “Stop Suffix” is the termination for a string of barcode messages. It can not be formatted like other suffix and prefix. It is fixed to the right and the very end of a barcode transmission.

  • Page 138: Message Interception & Pack

    Message Interception & Pack Introduction Barcode message could divide information into different sections, such as product ID, manufacture ID, and so on. They are important overall. However, at certain situations, some of them are not of interest. This is where message interception comes in. Message interception feature allows transmission of selected section(s).

  • Page 139: Message Interception

    Message Interception & Pack Message Interception & Pack Message Interception Tools Code Programming ON Interception Rule No.1: It only intercepts selected symbols’ raw barcode messages and it effects all barcodes of the barcode format. Interception Rule No.2: There are maximum 3 interception options restored in the non-volatile memory.

  • Page 140: Programming 1D Intercept Option

    Message Interception & Pack Message Interception & Pack Message Interception Tools Code Programming ON Programming 1D Intercept Option When programming 1D intercept option, read digit codes as interception command. The rules is as below： The interception command format of 1D interception command regards »...

  • Page 141: Programming 2D Intercept Option

    Message Interception & Pack Message Interception & Pack General Programming Tools Code Programming ON Programming 2D Intercept Option When programming 2D intercept option, read digit codes as interception command. The rules is as below： The interception command has two parts, which are barcode type »...

  • Page 142: Message Pack

    Message Interception & Pack Message Interception & Pack Message Pack Tools Code Programming ON Introduction Data Pack is for the special requirements of barcode message. There are 3 types of data pack. Data pack effects all data formats, in that be sure to load the default “Disable Pack”...

  • Page 143: Batch Programming

    Batch Programming Tools Introduction Code Programming ON Batch Programming can integrate a programming sequence into one barcode. Batch Programming Rules: 1、 Sub-command is in this format: Programming Command + Parameters 2、 Sub-commands are terminated by semicolons. Note that there is no blank between a sub-command and its terminator semicolon.

  • Page 144: How To Build A Batch Command

    Batch Programming How to build a batch command Batch command can contain many commands. Each command is divided by semicolon. Batch command must be ended with save command. Command structure: command (+ equal mark + setting information) The setting command list is provided below There are 4 setting command modes 1、...

  • Page 145: Produce Setting Code

    Batch Programming Produce setting code Make the command list (ended with save command) to a PDF417, QR code or DataMatrix. For example, to produce a batch command means: light Always On, Auto Scan, change delay time to 2 seconds, Disable Fixed Length of I 2 of 5. Firstly find commands as follows 0200030;（light Always On）...

  • Page 146: Use Batch Setting Code

    Batch Programming Batch Programming Use batch setting code Tools Code Programming ON Read “Code Programming ON”, then read “enable batch setting code”, and then read the batch setting code produced just now, finally Read “Code Programming Off” Code Programming OFF Code Programming ON 【Pro CMD：0006010】...

  • Page 147: Appendix

    Appendix Digit Code It is must to be read save after read digit code. 【Pro CMD：0000000】 【Pro CMD：0000040】 【Pro CMD：0000010】 【Pro CMD：0000050】 【Pro CMD：0000020】 【Pro CMD：0000060】 【Pro CMD：0000030】 【Pro CMD：0000070】 nlscan.com Page 138...
  • Page 148 Appendix Digit Code 【Pro CMD：0000080】 【Pro CMD：0000120】 【Pro CMD：0000090】 【Pro CMD：0000130】 【Pro CMD：0000100】 【Pro CMD：0000140】 【Pro CMD：0000110】 【Pro CMD：0000150】 nlscan.com Page 139...

  • Page 149: Save And Abort

    Appendix Appendix Save and Abort Tools Code Programming ON In order to save the received data “Save” has to be read after data transition completed. If error occurs when reading data, the wrong data can be deleted and the setting up can be done again.. Eg, after a program code is received then ‘1 2 3”...

  • Page 150: Factory Default List

    Appendix Factory Default List Parameters Factory Default Remark General Programming Code Programming Send Pro Code Value Illumination Illumination Wink Aiming Aiming Wink Decoding Beep Decoding Beep Type Type 1 Decoding Beep Volume Loud Power On Beep Working Mode Hand-held Mode One Reading Timeout 3000ms Multi-reading Semi-prohibit,...
  • Page 151 Appendix Factory Default List Parameters Factory Default Remark Symbol Code 128 Enable Max Message Length Min Message Length EAN-8 Enable Send Check Digit Enable 2 Digits Addenda Code Enable 5 Digits Addenda Code Expand to EAN-13 EAN-13 Enable Send Check Digit Enable 2 Digits Addenda Code Enable 5 Digits Addenda Code UPC-E...
  • Page 152 Appendix Factory Default List Min Message Length No less than 4 Specified Lengths ITF-6 Enable ITF-14 Enable Code 39 Enable Check Send Start & Stop Character Support Full ASCII Max Message Length Min Message Length Codabar Enable Check Send Start & Stop Character ABCD/ABCD, Upper Case Max Message Length Min Message Length...
  • Page 153 Appendix Factory Default List １Digit, MOD11 Check Max Message Length Min Message Length No less than 4 ISBN Enable Transmit 13 Digits Industrial 25 Enable Check Max Message Length Min Message Length No less than 4 Standard 25 Enable Check Max Message Length Min Message Length No less than 4...
  • Page 154 Appendix Factory Default List PDF417 Enable Read Single PDF417 Only Max Message Length 2710 Min Message Length Read Forward Direction Barcode Only Mirror Image Identifying QR Code Enable Read Single QR Only Max Message Length 7089 Min Message Length Aztec Enable Max Message Length 3832...

  • Page 155: Aim Id List

    Appendix AIM ID List Symbol AIM ID Possible AIM ID Modifiers(m) Code 128 UCC/EAN-128 EAN-8 EAN-13 EAN-13 with Addon UPC-E UPC-E with Addon UPC-A UPC-A with Addon 0,1,3 Interleaved 2 of 5 ITF-6 ITF-14 Code 39 0,1,3,4,5,7 Codabar 0,2,4 Code 93 Code 11 0,1,3 ISBN...

  • Page 156: Code Id List

    Appendix Code ID List Symbol Code ID Code 128 UCC/EAN-128 EAN-8 EAN-13 UPC-E UPC-A Interleaved 2 of 5 ITF-6 ITF-14 Code 39 Codabar Code 93 Code 11 GS1 Databar EAN•UCC Composite ISBN Industrial 25 Standard 25 Plessey MSI-Plessey PDF417 QR Code Aztec Data Matrix Maxicode...

  • Page 157: Symbols Id Number

    Appendix Symbols ID Number Symbol ID Number Code 128 UCC/EAN-128 EAN-8 EAN-13 UPC-E UPC-A Interleaved 2 OF 5 Code 39 Codabar Code 93 ISBN Industrial25 Standard25 Plessey Code11 MSI-Plessey EAN•UCC Composite GS1 Databar PDF417 QR Code Aztec DataMatrix Maxicode User-Define Code SPEC_OCR_B nlscan.com Page 148...
