Description of this Upgrade
Tools Required for the Installation
Tools Required for the Installation
Description
T-10 TORX driver - set to 9 in-lbs (1.02 N.m)
T-20 TORX driver - set to 21 in-lbs (2.38 N.m)
5/16-in (8 mm) nutsetter or open end torque wrench - set to 10 in-lbs (1.13 N.m)
5/16-in (8 mm) nutsetter or open end torque wrench - set to 21 in-lbs (2.38 N.m)
5/16-in (8 mm) nutsetter or open end torque wrench- set to 8 in-lbs (0.9 N.m)
5/8-in (16 mm) nutsetter or open end torque wrench - set to 21 in-lbs (2.38 N.m)
Needle nose pliers
Flat head screwdriver
Use a 5/16-in torque wrench set to 10 in-lbs on all cable connections
except the front and rear panel bulkhead connectors. On these, use a
9 mm nutsetter or open end torque wrench set to 21 in-lb.
About Installing the Upgrade
Products affected
Installation to be performed by
Estimated installation time
Estimated adjustment time
Estimated full instrument calibration time
8
All N5221/2B, N5241/2/9B 4-port microwave network analyzers
Keysight service center, personnel qualified by Keysight, or
customer
4 hours
3 hours
4.5 hours
Installation Note N5222-90133
Qty
1
1
1
1
1
1
1
1
