Items Included in the Upgrade Kit
Check the contents of your kit against the following list. If any part is missing or
damaged, contact Keysight Technologies. Refer to
Upgrade" on page
This section applies to multiple models and upgrade kits. Please refer to
the model and upgrade kit for your instrument's upgrade.
Extra quantities of items such as protective plastic caps, screws, cable ties,
and cable clamps may be included in this upgrade kit. It is normal for some
of these items to remain unused after the upgrade is completed.
Table 1
Contents of Upgrade Kit N5222-60133 Option 4S7
Qty
1
Installation Note (this document)
1
China RoHS Addendum
A11 – Direct digital synthesizer (DDS) assembly (Assembly contains four
1
synthesizers)
8
Rivet-Plastic Flat-HD 0.17-in-DIA 0.33-0.39-in-Grip-Range Nylon Black-finish
2
Screw-Machine W/Crest-Cup-Con-Washer Pan-HD Torx-T10 M3X0.5 8mm-LG
SST-300 Passivated
4
Screw-Machine with Crest-Cup-Con-Washer Pan-HD Torx-T10 M3X0.5 10mm-LG
SST-300 passivated finish (bracket-center, stabilizer (all options), short, x2 short and
rear panel bracket–Option 422/423 only)
4
Screw-Machine W/Crest-Cup-Con-Washer Pan-HD Torx-T10 M3X0.5 8mm-LG
SST-300 Passivated – (x2 secure DDS to chassis)
1
Microwave Plug SMA Male Straight 50-Ohm
2
Fan-Guard 115.3X115.3X5.5-mm Steel Nickel-plated
2
Fan, TBAX 12 VDC 82.67-CFM
2
Washer-Flat non-metallic, Fiber Gray
Cable assy-RF, A11 13.5 GHz (SRC 1) direct digital synthesizer (J4)-SRC 1 RF IN –
1
W1
1
Cable assy -RF, A11 13.5 GHz (LO) direct digital synthesizer (J5)-HMA RF IN – W41
Cable assy-RF, A11 13.5 GHz (SRC 2) direct digital synthesizer (J6)-SRC 2 RF IN –
1
W2
1
Cable assy –RF, A11 J7 to rear panel (Option 422/423 only) – W201
1
Bracket, rear plate (Option 422/423 only)
Installation Note N5222-90133
3.
Description
"Description of this
Part Number
N5222-90133
9320-6722
N5240-60102
0361-1272
0515-0372
0515-0374
0515-0380
1250-4261
3160-0281
3160-4199
3050-0023
N5240-20121
N5240-20122
N5240-20123
N5240-20127
N5240-00015
9
