5 Preparing the pressure washer for operation

► Do not charge, open, dispose of in fire or
short-circuit batteries.
■ If the battery is swallowed, serious injuries or
death may result within 2 hours due to internal
burns and perforation of the esophagus.
► Keep the battery and the control panel out
of the reach of children and other unauthor‐
ized persons.
► Always close the cover of the control panel
tightly. If it is not possible to close the
cover, remove the battery and have the
control panel by a STIHL servicing dealer
replaced.
► If the battery is swallowed: do not induce
vomiting. This could result in the battery
lodging in the esophagus. Seek medical
advice immediately.
■ A battery which is believed to be completely
discharged may still produce a dangerous
short-circuit current or may leak. This may
result in serious injury to people and damage
to property.
► Comply with all the statutory disposal regu‐
lations. Dispose of discharged batteries
immediately. Do not dismantle them. Do not
dispose of them by burning.
5 Preparing the pressure
washer for operation
5.1 Making the pressure washer
ready for use.
The following steps must be performed before
commencing work:
► Make sure that the pressure washer, the high-
pressure hose, the hose coupling and the con‐
necting cord are in a safe condition,
► Cleaning the pressure washer,
► If using a water filter: Check the water filter for
dirt and clean it if it is dirty,
► Set up the pressure washer on a firm and level
base, where it will not slide or tip over.
► Unroll high-pressure hose from hose reel,
10.2.
► Connect spray gun,
► Fit spray lance,
► If using a nozzle: Attach the nozzle,
► If using a detergent: Using detergents and the
detergent bottle,
► Connect water supply,
► Connect pressure washer to power supply,
8.
0458-004-0121-B
4.6.
14.2.
14.5.
6.3.
6.4.
6.5.
10.6.
7.
► If it is not possible to carry out these steps: Do
not use the pressure washer. Consult a STIHL
servicing dealer.
6 Assembling the pressure
washer
6.1 Assembling the high-pressure
washer
Installing handle with hose reel
2
3
► Slide the handle (1) onto the holder (2).
► Insert screws (3) and tighten.
Connecting the hose reel
2
1
► Fit the connecting piece (1) into the coupling
(2).
The connector (1) engages with an audible
click.
► Secure the cover (3) with the screw (4).
Inserting nozzles
1
► Insert 3-in1 nozzle (1).
English
1
3
4
