English
Removing the water hose
2
1
► Turn off tap.
► To unlock the coupling: Pull the ring (1) or
twist and hold it.
► Pull the coupling off the connector (2).
7.2 Connecting the high-pressure
washer to another water supply
The high-pressure washer can draw in water
from water butts, storage tanks and flowing or
still rivers and lakes.
So that the water can be drawn in, the height dif‐
ference between the high-pressure washer and
the water source must not exceed the max. suc‐
tion lift (a), 18.1.
The appropriate STIHL suction set must be used.
The suction set includes a water hose with a
special coupling.
Depending on the market, the appropriate STIHL
suction set may be included with the high-pres‐
sure washer.
Connecting the water filter
If the high-pressure washer is operated with
water containing sand from water butts, cisterns
or from flowing or still rivers and lakes, a water
filter must be connected to the high-pressure
washer.
Depending on the market, the water filter may be
included with the high-pressure washer.
14
a
7 Connecting to a water source
2
1
3
► Unscrew the connector (1).
► Insert water intake screen (2) into the coupling
of the water hose (3).
Connecting the water hose
3
2
1
► Fill the water hose (1) with water so that no air
is present in the water hose any more.
► Screw the coupling (2) onto the connector of
the pressure washer (3) and tighten by hand.
► Attach the suction cup (4) to the water source
so that the suction cup (4) does not touch the
ground.
► If the spray gun is fitted to the high-pressure
hose: Remove the spray gun.
► Hold the high-pressure hose downwards.
► Switch on the high-pressure washer until an
even water jet flows out of the high-pressure
hose.
NOTICE
■ If the high-pressure washer does not suck in
water, the pump may run dry and the high-
pressure washer may be damaged.
► If no water escapes from the high-pressure
hose after two minutes: Switch off the high-
pressure washer and check the water sup‐
ply.
► Switch off the high-pressure washer.
► Connect the spray gun to the high-pressure
hose.
► Press and hold down the spray gun trigger.
► Switch on high-pressure washer.
1
4
