FUNCTION INTRODUCTION &
INSTRUCTIONS FOR USE
① MENU ：
DMX SETTINGS (Figure 1):
Set the DMX parameters, [address (001-512)]
and configure the mode [(8bit/16bit)].
DIM CURVE (Figure 2):
Set the dimming curve, [linear / logarithmic /
exponential / S curve].
WL SETTINGS (Figure 3):
RF channel settings, RF switch, Bluetooth
switch, Bluetooth reset.
STUDIO (Figure 4):
Set the studio mode and non-studio mode.
Studio mode：Brightness remains the same
of last setting after power-on.
Non-Studio mode: Brightness reset to default
setting after power-on.
FREQUENCY SETTINGS (Figure 5):
Set the dimming frequency.
FAN SETTINGS (Figure 6):
Set the cooling fan mode.
Figure 1
MENU
DMX SETTINGS
Figure 2
MENU
DIM CURVE
Figure 3
MENU
WL SETTINGS
Figure 4
MENU
STUDIO
Figure 5
MENU
FREQUENCY SETTINGS
Figure 6
MENU
FAN SETTINGS
12
DMX SETTINGS
PROFILES ADDRESS
8bit 1
16bit
DIM CURVE
Linear Exp
Log S
WL SETTINGS
RF Channel 1
RF Switch
OFF
Bluetooth
ON
BT Reset YES NO
STUDIO
ON
FREQUENCY SETTINGS
30000
Hz
FAN SETTINGS
Smart High Silent
