- Page 1 GVM-480LS Buku Manual...
-
Page 2: Pengenalan Produk
Pengenalan Produk Welcome to "Lens light series". This product is specially designed for senior photography lovers. The product is suitable for live broadcast / outdoor / studio photography, etc. It can also be used for YouTube video shooting.The main features of the product are: ①... -
Page 3: Petunjuk Keselamatan
Catatan Penting Before using this product, please read the instructions carefully and make sure use the product correctly. If you don’t obey the instructions and warnings, you maybe cause harm to yourself and the people around, or even damage the product and other things around. - Page 4 GVM-480LS Spesifikasi Product model : GVM-480LS Brand : GVM Product Name : Photography lights Product Type : Photography Fill Light Features / Features : APP, Joint control Color rendering index : ≥97 Color temperature : 3200K~6800K Brightness : 15000 lux / 20 inch...
- Page 5 Bagian folding Vents Lens Angle fixing knob U-frame Power interface Light stand Light frame fixed button interface Cooling fan Indicator light Mode selection button Power interface Mode/WIFI button Adapter interface Brightness Color temperature adjustment knob adjustment knob Electronic display V buckle battery/ Battery gusset interface...
- Page 6 Cara Memasang LED The lamp can be installed and fixed on the bracket by rotating the knob clockwise, and unloaded by rotating in the counterclockwise direction.
- Page 7 Insert the Subdued light board from the top of the light panel. Loosen the adjustment knobs on both sides of the U-bracket, a djust the angle of the panel you need, and then tighten the adjustme nt knobs on both sides of the U-bracket.
- Page 8 There are two power supply modes to choose from: ① Connecting lamp and adapter. Plug in the adapter power cord for power supply. ② Plug in the battery, connect the lamp and the D-TAP port of t he battery with the battery connection line, and use the battery to supply power. Connecting light and adapter Adapter power...
- Page 9 Pengenalan Tombol DC15V power input interface Power switch Mode button/WIFI reset button: Modes include host mode and slave mode; WIFI username and password reset button Channel addition and subtraction key: adjust channel ( 0~11 ) Brightness indicator: when adjust the brightness knob, the indicator is on Color temperature indicator: when adjust the color temperature knob, the indicator is on...
- Page 10 Cara Penggunaan ① Mode selection： The mode is divided into master mode and slave mode. Tap the mode key to switch (default master mode for startup). MODE:Master：Adjust brightness, color temperature and channel through knobs and buttons, and can also connect APP. These parameters of lamp can be controlled through APP, and slave computers of the same channel can also be adjusted synchronously.
- Page 11 be on and the brightness indicator will be off. S l a v e m o d e : c o l o r t e m p e r a t u r e i n d i c a t o r a n d b r i g h t n e s s i n d i c a t o r a r e a l w a y s o n .
- Page 12 Scan the QR code on the back of the manual to download the APP Set host mode for the photography light ( automatically as host mode when , open “GVM Easily” APP on the mobile phone switch on the machine ) , in the main menu in the APP----switch ( meanwhile turn on WIFI on the phone ) the devices---select “single and double photography light”,then in the...
- Page 13 WIFI username and password resetting It is able to reset the WIFI username and password if long press the WIFI reset button for over 5 seconds. After resetting, the username and the password will return to the initial ( WIFI username: GVM_LED, WIFI password: gvm_admin ) Perawatan Do not put the product in highly humid, strong electromagnetic field, direct sunlight, high temperature environment.
-
Page 14: Troubleshooting
Troubleshooting Troubleshooting Check the product Phenomenon Make sure the adapter ① Check the matching power adapter is well contacted with indicator light up or not. The switch the power plug indicator does ② When using lithium battery, make not light up Charge the battery s u r e t h e r e ’s n o “... - Page 15 Download APP Download APP GVM Official Facebook Android website Web: www.gvmled.com B&H Email: bh@gvmled.com GVM Email: support@gvmled.com Amazon Email: gvmledservice@hotmail.com amazonsupport@gvmled.com...
