PRODUCT STRUCTURE DIAGRAM

Control input
Vents
Light stand interface
Return key
Display screen
Menu key
Mode key
Cooldown key
Knob①:
Brightness adjustment /
selection confirmation
Knob②:
CCT adjustment /
rate adjustment
Power button
Light
Controller
5
Vents
Bowens mount
lamp beads
Angle lock handle
U-frame
Fixture knob
Battery plate
controller output
interface
DMX output
interface
DMX input interface
AC
input
