INSTALLATION AND OPERATION MANUAL
DHCP Stop IP
Address
DHCP Netmask
DHCP Gateway IP IP address for the network segment gateway that the DHCP sever will
DHCP Lease
Times
Remember to select Apply Settings if any changes were made.
8.5.2 NETWORK SETTINGS Page DHCP SERVER RESERVATIONS Section
Here one can assign IP addresses to specific MAC addresses. Once the IP address and MAC
address has been entered, click the ADD button. Make sure the IP address assigned is within
the DHCP start and end address block.
Remember to select Apply Settings if any changes were made.
8.5.3 NETWORK SETTINGS Page BANDWIDTH CONTROL Section
When enabled is checked, this will limit up and download speeds specified by the page that will
launch when the configure button is pressed as shown below:
Enter in the throughput limiting values for upload and download then hit the Apply Setting
button. This feature could be useful when configuring clients connecting to a single multipoint
AP or in a repeating system thus keeping within the maximum throughput of any one hop or
multipoint AP.
TECH SUPPORT: 1.888.678.9427
DHCP address block stop address
DHCP Network mask that the DHCP sever will pass to the DHCP
clients
pass to the DHCP clients
Lease time for the DHCP addresses. Default is 1 hour or 3600
seconds.
NW1/NW2
INS_NW(1,2)_REV– 06/10/13 PAGE 30
