This manual serves the following
ComNet Model Numbers:
NW1
NW2
NWK1
NWK2
INSTALLATION AND OPERATION MANUAL
INDUSTRIAL OUTDOOR 802.11A/N WIRELESS ETHERNET
Thank you for purchasing Netwave
walk you through installation.
This guide applies to the following models:
NW1: Industrial Multipoint, FCC Version, User Configurable
NW2: Industrial Multipoint, ETSI Version, User Configurable
NWK1: Industrial Point to Point Kit, FCC Version (Includes NWK1_AP and NWK1_CL)
NWK2: Industrial Point to Point Kit, ETSI Version (Includes NWK2_AP and NWK2_CL)
An easy to read LED array displays unit operational status along with received signal
strength ensuring optimal installation and operation. See Figure 2 on Page 2 for LED
Indicator explanations.
See Figures 3 through 5 beginning on Page 3 for mounting instructions.
from ComNet. This quick start guide is designed to
®
INS_NW1_NW2_QS_REV– 05/20/13 PAGE 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Comnet NW1
Summary of Contents for Comnet NW1
- Page 1 INSTALLATION AND OPERATION MANUAL INDUSTRIAL OUTDOOR 802.11A/N WIRELESS ETHERNET Thank you for purchasing Netwave from ComNet. This quick start guide is designed to ® This manual serves the following walk you through installation. ComNet Model Numbers: This guide applies to the following models:...
- Page 2 QUICK START USER GUIDE NW1/NW2 FIGURE 1 – NW1/NW2 INDUSTRIAL WIRELESS ETHERNET LINK BOTTOM FIGURE 2 – STATUS LED INDICATIONS VISUAL CUE INDICATION SOLID RED Power is supplied to the NW1/NW2 POWER No power is supplied to the NW1/NW2 SOLID RED...
- Page 3 QUICK START USER GUIDE NW1/NW2 FIGURE 3 – INSTALLATION INSTRUCTIONS Step 1. Unpack the mounting hardware from the box. Determine if this will be a pole or wall mount application. The included Mounting kit is designed to support poles up to 3" in diameter as well as surface or wall mounting.
- Page 4 QUICK START USER GUIDE NW1/NW2 FIGURE 4 – POLE MOUNT INSTRUCTIONS Included Hardware Vertical Mount in -45º Position Vertical Mount in +45º Position FIGURE 5 – OPTIONAL POLE MOUNT HARDWARE ComNet Part NWBKT1 TECH SUPPORT: 1.888.678.9427 INS_NW1_NW2_QS_REV– 05/20/13 PAGE 4...
-
Page 5: Installation Requirements
8 Select the WIRELESS SETTINGS tab and set: • Wireless mode – Set to AP or Client (Only need to do this on the NW1 and NW2 models) • Country code – Only required if setting up the NW2 and NWK2 (ETSI) models NOTE: It is the user’s responsibility to ensure that the correct country is chosen. - Page 6 TYPICAL POINT-TO-MULTIPOINT CONFIGURATION NOTE: NW1 and NW2 Multipoint nodes will need to have the Wireless Mode set to either AP or Client (default is Client). And the IP addresses will need to be all set to different addresses (default address is 192.168.10.101). Once this is done, all the clients will connect to the multipoint AP with all other setting kept at default.
- Page 7 QUICK START USER GUIDE NW1/NW2 AGENCY COMPLIANCE Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: •...
- Page 8 T: +44 (0)113 307 6400 | F: +44 (0)113 253 7462 | INFO-EUROPE@COMNET.NET © 2013 Communications Networks Corporation. All Rights Reserved. “ComNet,” the “ComNet Logo,” “Netwave,” and the “Netwave Logo” are registered trademarks of Communication Networks, LLC. INS_NW1_NW2_QS_REV– 05/20/13 PAGE 8...
