This guide serves the following
ComNet Model Numbers:
CNFE3TX2CXMSU
CNFE3TX2CXMSE
QUICK START GUIDE
CNFE3TX2CXMS(U,E)
4G LTE Cellular VPN Gateway
The ComNet CNFE3TX2CXMS(U,E) is an edge Cellular VPN Gateway with 2 10/100TX
Ports and 1 SIM Card slot. It supports 802.1X and MAC filter for security control. The
Gateway can be configured to operate in 3 modes: Dynamic/Static IP route, PPPoE
authentication, and Modem dial up. The units can be powered by an IEEE 802.3af PoE
compliant device on port 1 or through the 4-Pin terminal block with dual DC Inputs.
The Gateways are DIN Rail mountable and feature a rigid IP-30 housing.
Rev. 7.11.18
