8.1.3 STATUS_AP Page RADIO Section
Wireless Mode
Local AP SSID
Frequency
MAC
Local AP MAC
Security
8.1.4 STATUS_AP Page CONNECTED STATIONS Section
MAC Address
Signal Strength
Tx Rate
TX CCQ
Channel Width
Refresh Button
TECH SUPPORT: 1.888.678.9427
Shows the operational mode for the radio. This can be set on the
WIRELESS SETTINGS page.
SSID that this AP is broadcasting.
Frequency that the AP is operating on
MAC address of the AP radio
MAC address of the AP radio
Operating security. This can be selected on the WIRELESS SETTINGS
page
Lists the MAC addresses of the connected stations
Lists the RSSI values of the connected stations
will show the transmit radio connection rate
Client Connection Quality. Given in % and provide the radio
connection quality with the connected AP with 100% being the best.
channel width the radio connection is using. This is automatically
determined based on the radio connection quality when 20/40M
channel bandwidth is selected on the WIRELESS SETTINGS page.
Possible connections that may be displayed are listed below starting
with the best/fastest connection
HT40+
HT40
HT40-
HT20
HT10
This will cause the data that feeds this page to be refreshed.
