INSTALLATION AND OPERATION MANUAL
8.3.1 WIRELESS SETTINGS-AP Page BASIC WIRELESS SETTINGS Section
Note: Any settings changes made on this page will require the hitting Apply Settings button then
Select Save.
Wireless Mode
Local AP-ESSID
Country Code
Wireless Profile
Channel
Spectrum Width
Guard Interval
Channel
Frequency
Select Button
TECH SUPPORT: 1.888.678.9427
The user can select either Access Point or Client mode of operation.
The SSID this AP will broadcast.
A country of operation can be selected from the pull down.
NOTE: For the FCC version, only United States will be in the list while
countries participating in the ETSI harmonized standards will populate this
list for the ETSI version.
Select either NA or NG operation. NA is 802.11a and 802.11n (5GHZ
operation). NG is 802.11g and 802.11n (2.4GHz operation).
NOTE: Some models may only support the NA (5GHz) option.
The user can select the operation channel width. 20/40M lets the units
determine the best channel width with the maximum 40MHz as an
option under good RF conditions. One may want to choose 20MHz for
noisy or congested RF environments. Options available are 20/40M,
20M, and 10M.
This represents the guard interval between packets. The options are
Short and Long. The Long option is recommended for links greater
than 2Km in distance.
Auto is enabled by default. When Auto is unchecked, the user can
select from a number of frequencies available from the drop down
list. When Auto is checked and during boot up, the AP will select the
operational channel with least interference.
When pressed, a pop up screen comes up like the one below:
This allows the user to select which frequencies the AP will scan for
during reboot and when Auto mode is checked/enabled.
NW1/NW2
