Wiring Diagram - Directed DS3+ Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Body ECU Connector
(Black lower conn. left side
of steering column)
2
2 1
13 12 11 10 9 8 7 6 5 4 3
21 20 19 18 17 16 15 14
(-) Unlock/Disarm: Tan, pin 17
AG4
(white conn. left
of body ECU)
(-) Lock/Arm:
Lt. Green, pin 18
1
12
2 13
3 14
(+) Starter:
4
Blue, pin 5
5
15
6 16
7 17
8
9
18
10 19
11 20
(-) PTS: Gray, pin 5
ENGINE
START
5 4 3 2 1
STOP
10 9 8 7 6
PTS Button
(Black conn. at PTS switch)
18 17 16 15 14 13 12 11 10 9
40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25
Headlight Switch
(White 40-pin conn.)
8 933.TL15 1.13.198.9 2023 Toyota RAV4 Hybrid (Smart Key)
©2023 VOXX•DEI LLC. All rights reserved.
Body ECU
Connector
1
2
3
Cut
Telematics
Cut
Interrupt:
Black, pin 33
Autolight:
56
Yellow, pin 5
14
33
8 7 6 5 4 3 2 1
24 23 22 21 20 19
6
19
1
36
Plug 3A
(white connector rear of
dash fuse box)
Body ECU
(Black middle conn. left side
of steering column)
1
5 4
19 18 17 16 15 14 13 12 11
30 29 28 27 26 25 24
HS CAN High: HS CAN Low:
Tan, pin 5 Violet, pin 4
Hood Pin
Siren
Autolight Interrupt (conn. side): Blue/White: 1
Telematics Interrupt (conn. side): White/Brown: 4
Telematics Interrupt (vehicle side): White: 5 & 11
(+) 12V:
White, pin 1
3
(-) SLP:Tan, pin 4
1
Dash Fuse Box
(white conn.)
Black Steering Lock conn.
3 2 1
9 8 7 6
10
23 22 21 20
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
(-) Lock Output: Dk. Green/Black: 3
(+) Starter Output: Violet/Black: 8 Do not insert 15A fuse
(-) Unlock Output: Dk. Blue/Black: 9
(-) Push-to-Start Output: Lt. Blue/Black: 10
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
Autolight Interrupt (vehicle side): Blue: 3
(+) 12V Input: Red: 6 & 12
(-) Ground: Lt. Green/Red: 7
(-) SLP Output: Lt. Green: 8
(-) Ground: Black: 10
SLP connection is
only required if
the connector is
present in the
vehicle.
(at steering lock conn.)
).
A module can also be used for
this installation.
Do not insert 15A fuse
IMPORTANT:
Position the
fuses correctly!
Slide to open
Legend:
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
