Installation; Wiring Diagram With T-Harness (Thton7) With Slp Connector - Directed DS3+ Installation Manual

Wiring diagram with T-Harness (THTON7)
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Body ECU Connector
(Lower conn. left side
of steering column)
2
1
Telematics
Interrupt:
56
2
14
Black, pin 33
33
Cut
Body ECU
6
Connector
19
1
36
Plug 3A
(white connector rear of
dash fuse box)
AG4
(white conn. left
of body ECU)
When using a THTON7 T-harness and
flashing with security only, a Starter Disable
Connection can be made with no external relay.
1 12
Refer to the Vehicle Connections section.
2 13
3
14
(+) Starter:
4
Blue, pin 5
5 15
6 16
7
17
8
9 18
10 19
11 20
6 933.TL15 1.13.198.9 2023 Toyota RAV4 Hybrid (Smart Key)
©2023 VOXX•DEI LLC. All rights reserved.
with SLP connector
Body ECU
(middle conn.
left side of steering column)
1
(-) PTS: Gray, pin 5
Siren
ENGINE
START
5 4 3 2 1
STOP
10 9 8 7 6
PTS Button
(Black conn. at PTS switch)
Headlight Switch
(-) Push-to-Start Output: Lt. Blue/Black
(+) Siren Output: Brown/Red
Hood Pin
(-) Hood Input: Gray
Telematics Interrupt (conn. side): White/Brown
Telematics Interrupt (vehicle side): White
CONNECT the white
12-pin connector to
the 12-pin Red
connector labeled C.
Starter Disable (conn. side): White/Brown
Starter Disable (veh. side): White
(+) Starter Output: Violet/Black
Steering Lock
(black 7-pin connector)
NOT USED
NOT USED
A
B
Cut the
Orange/Black loop.
A module can also be used for
this installation.
8-pin White Connector
Do not insert 15A fuse
22-pin White Connector
THTON7
IMPORTANT:
(optional T-Harness)
Position the
fuses correctly!
12-pin Black Connector
C
).
B
Do not insert 15A fuse
Slide to open
Legend:
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
