Pre-installation and application warnings

This section highlights important information for this specific firmware and will assist in pricing accordingly, as
START HERE
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
compatible
Vehicle Takeover
Firmware notes
OEM remote starter detection: If the vehicle is already equipped with an OEM remote starter, the installer must disconnect it before
Š
installing the DS4+ otherwise it will not program. (For more information see "OEM remote starter detection")
Motorized Hatch feature: If available, the Motorized Hatch feature needs to be enabled using the configuration tool found on the
Š
module flashing page on www.directechs.com.
Remote Start: To remote start the vehicle, all doors must be closed and locked.
Š
Manual Transmission: For manual transmission vehicles, "Safelock" needs to be enabled for proper remote start operation.
Š
The optional Plug & Play THTON7 T-Harness is sold separately.
Š
Loose T-harness wires: All T-Harness wires not listed in the diagram are not required for the installation. Loose wires such as
Š
Siren Output and Hood Input may need to be pulled from the tapped section of the T-Harness. Refer to the "Wiring diagram with
T-Harness" for more information on connections and installation instructions.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic connector.
Š
Refer to the "Vehicle connections" following the installation diagram.
Š
Footnotes
Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin if or
[1]
not supported in Data.
Siren: The siren is only required when enabling the security features during module flashing.
[2]
PTS: This connection is only required for Pit Stop/ Idle mode in manual transmission vehicles or Ready mode for vehicles with hybrid
[3]
engines.
SLP: Depending on the production date of your vehicle, there may not be an SLP connector at the steering column.
[4]
- Installation with SLP connector: the connection is mandatory.
- THTON7 T-Harness installation without SLP connector: you must make modifications to the T-Harness for the (12V) & (Ground). See
wiring diagram for additional information.
- Hardwire installation without SLP connector: Connection not required.
See "Locating Steering Lock Connector in Vehicle" in Vehicle connections.
Security-only: For security-only installations using THTON7 T-Harness, refer to the "Locating components in the vehicle" section for
[5]
optional starter disable.
White/Brown wires to starter wire in the vehicle (No external relay required).
Telematics Interrupt: Depending on the production date of your vehicle, if remote start fails, a "Telematics Interrupt" connection may
[6]
be required.
5
933.TL15 1.13.198.9 2023 Toyota RAV4 Hybrid (Smart Key)
©2023 VOXX•DEI LLC. All rights reserved.
THTON7
No takeover feature is available on Push-to-Start vehicles. The engine will stop when a door is open.
Important!
When flashing security-only, configure relay 3 to Starter Kill. Connect the White and
Keys required for 1 Keys required
programming for operation
0
