primary harness (H1), 12-pin connector

primary harness wiring diagram

___
ORANGE
H1/1
___
WHITE
H1/2
___
WHITE/BLUE
H1/3
___
BLACK/WHITE
H1/4
___
GREEN
H1/5
___
H1/6
BLUE
___
H1/7
VIOLET
___
H1/8
BLACK
___
H1/9
YELLOW
___
H1/10
BROWN
___
H1/11
RED
___
H1/12
RED/WHITE

primary harness wiring guide

This guide describes in detail the connection of each wire. Also included are possible applications of each wire.
This system was designed with the ultimate in flexibility and security in mind. Many of the wires have more than
one possible function. Please read the instructions carefully to ensure a thorough understanding of this system
and how it operates.
H1/1 ORANGE (-) GROUND-WHEN-ARMED OUTPUT
This wire supplies a (-) ground as long as the system is armed. This output ceases as soon as the system is
disarmed. The orange wire is pre-wired to control the P/N 8618 starter kill relay. It can supply up to 500 mA of
current.
NOTE: If connecting the orange wire to control another module, such as a P/N 529T or P/N 530T
window module, a 1 amp diode (type 1N4004) will be required. (See the following diagram.)
© 2001 Directed Electronics, Inc. Vista, CA
(-) 500 mA GROUND-WHEN-ARMED OUTPUT
(+/-) SELECTABLE LIGHT FLASH OUTPUT
(-) 200 mA CHANNEL 3 PROGRAMMABLE OUTPUT
OUTPUT OF DOMELIGHT SUPERVISION RELAY #30
(-) DOOR TRIGGER INPUT, ZONE 3
(-) INSTANT TRIGGER INPUT, ZONE 1
(+) DOOR TRIGGER INPUT, ZONE 3
(-) CHASSIS GROUND INPUT
(+) SWITCHED IGNITION INPUT, ZONE 8
(+) 12V CONSTANT POWER INPUT
OUTPUT OF CHANNEL 2 RELAY #30
(+) SIREN OUTPUT
