CyberData 011579 Operation Manual page 91

Table 2-25
Note
Web Page Item
Enable Event Generation
Events
Enable Call Start Events
Enable Call Terminated Events
Enable Relay Activated Events
Enable Relay Deactivated Events
Enable Night Ring Events
Enable Multicast Start Events
Enable Multicast Stop Events
Enable Power On Events
Enable Fault Events
Enable 60 Second Heartbeat
Enable Temp Threshold Events
Enable Protection Mode Events
Enable Recovery Temp Events
Enable Audio Clip Events
Event Server
Server IP Address
Server Port
Server URL
Check All
Uncheck All
CyberData Corporation
shows the web page items on the Events page.
The question mark icon (
after the Toggle Help button is pressed
Table 2-25. Events Configuration
Description
The device will send HTTP POST events to the specified remote server and port
number whenever a certain action takes place. Select an event type below to
generate an HTTP POST event. See
Events" for sample packets.
When selected, the device will report the start of a SIP call.
When selected, the device will report the end of a SIP call.
When selected, the device will report relay activation.
When selected, the device will report relay deactivation.
When selected, the device will report when it starts ringing upon an incoming SIP
call to the Nightringer extension. As a reminder, the Nightringer extension always
rings upon an incoming SIP call and it is not possible to alter this behavior.
When selected, the device will report when the device starts playing a multicast
audio stream.
When selected, the device will report when the device stops playing a multicast
audio stream.
When selected, the device will report when it boots.
When selected, the device will report when the on-board fault detection is
activated.
When enabled, the device will report a Heartbeat event every 60 seconds. SIP
registration is not required to generate Heartbeat events.
When selected, the device will report a temperature threshold event.
When selected, the device will report a protection mode event.
When selected, the device will report a recovery temperature event.
When selected, the device will report an event when a waveform that is playing is
distorted, possibly indicating that the amplifier is overdriven.
The IPv4 address of the event server in dotted decimal notation.
Specify the event server port number. The supported range is 0-65536. Enter up
to 5 digits.
Generally, the destination URL is the name of the application that receives the
events and the string in the HTTP POST command. It can be a script used to
parse and process the HTTP POST events. Enter up to 127 characters.
Click on Check All to select all of the events on the page.
Click on Uncheck All to de-select all of the events on the page.
Click the Save button to save your configuration settings.
931996A
Setting Up the SIP Paging 25V/70V Amplifier
) in the following table shows which web page items will be defined
.
Section 2.6.16.1, "Example Packets for
Configure the Event Parameters
Operations Guide
83
