The parameters for the Configure PGROUP window are shown in
Web Page Item
PGROUP
Address
Port
Name
Security Code
TTL
Line-out
Play Stored Message
Audio File
Times to Play
Send Polycom Page
Polycom Transmit Channel
CyberData Corporation
Table 2-12. Configure PGROUP Window
Description
Shows the paging group number.
Enter the IP address of the PGROUP.
Note: To disable a relay on a group, use an IP address of 0.0.0.0.
Enter the port number of the PGROUP.
Note: The port range can be from 2000 to 65534 and must be even. When configuring a Paging
Group for Polycom Group Paging using an odd-numbered port, configure the next lower even
port number. For example, when using the default Polycom paging port 5001 on Polycom
phones, configure the next lower even port 5000 for the desired device's Paging Group port.
Enter a name for the PGROUP.
This field allows the user to add a security code to prevent unauthorized paging to the
PGROUP. Code must be between two to five numeric digits (0 through 9). Leave the field empty
for no security code. Any security code entered for PGROUP 0 will be ignored if DTMF is
bypassed.
The TTL field allows you to adjust the TTL. TTL is "time to live" and it describes how many
networks (routers) a packet will go through before it is discarded.
The Lineout field determines whether or not the device will play audio out of the RCA output
port and the 600 Ohm output port in addition to forwarding it to the PGROUP.
When selected, entering this paging group will play the stored message selected in
Select a file from the drop down list of audio files previously saved in the
portion of the Audiofiles Page.
Enter the number of times the message will play (1-65535).
Enabling Polycom Paging will result in a standard RTP multicast being sent to the specified
address and port and a Polycom Group Paging multicast being sent to the specified address
and port+1. Tied to the specified paging group.
Destination channel for Polycom Group Paging multicast
Click on the Toggle Help button to see a short description of some of the web page items. First
click on the Toggle Help button, and you will see a question mark (
the web page items. Move the mouse pointer to hover over a question mark to see a short
description of a specific web page item.
Click the Cancel button to close the Configure PGROUP window.
Click the OK button to save your configuration settings.
931996A
Setting Up the SIP Paging 25V/70V Amplifier
Configure the Paging Groups (PGROUPS) Parameters
Table 2-12.
) appear next to some of
44
Audio File.
Stored Messages
