True View Hardware Integration Kit (M600); Installing The Top Plate And Controller Box - GeoCue True View 515 Hardware User's Manual

True View 515 Hardware User Guide

True View Hardware Integration Kit (M600)

The True View 3DIS was designed to be used with the GeoCue True View Integration kit, which includes
an antenna mounting plate and a DJI Ronin gimbal mount with vibration dampeners. If your True View
3DIS and M600 were purchased through GeoCue, the antenna mounting plate and Ronin mount were
installed by a GeoCue technician. If you purchased your M600 from a third party, you will need to install
these components before using your True View system. The following steps explain how to install your
True View integration kit.

Installing the Top Plate and Controller Box

1. To install the top plate and controller box you will need the following components:
a. Top plate with antenna mast. (Figure 1)
b. Controller box without LED Readout (Figure 2) or with LED readout (Figure 3)
6
Figure 1 – Top Plate with Antenna Mast
Figure 2 – Controller box without readout display
