True View 3DIS/M600 Pro – Mission Checklist
Step
1. Setup base station and turn ON.
2. Check mission plan; modify if necessary.
3. Complete a safety briefing and flight plan review with field crew.
4. Install True View on drone mount. Lidar "top hat" at the back.
5. Verify Ronin red lever is fully tightened.
6. Verify safety cable attached between True View and drone rails.
7. Install fully charged True View battery pack. Do not turn the unit ON.
8. Check all drone GPS antennas upright and secured.
9. Verify True View CAT 6 and antenna cables are plugged into the unit and Controller
box.
10. Verify parachute attached and set to locked position and attach clips.
11. Verify the True View UMS memory stick is inserted.
12. Move drone/True View to take-off location.
13. Unfold and secure drone arms, lock in place.
14. Unfold drone propellers, visually inspecting for any problems.
15. Install fully charged drone batteries. Do not turn the unit ON.
16. Double-check all cabling is secure and won't interfere with the props.
17. Remove True View lens caps; clean lenses/sensor if necessary.
18. Power on True View using main power button located just above the battery
pack (door must be open to toggle).
19. Monitor the True View Controller status lights waiting for:
1. PWR - Solid Green/Yellow/Red
2. GNSS - Solid Green – Valid date/time stamp received.
3. SYS – Flashing Green - True View has initialized, ready for takeoff.
20. Turn on drone controller then power on the drone as per normal operations.
21. Wait for drone to initialize and verify there are no errors showing.
22. Parachute LED is solid blue (If Applicable)
23. Safety Check: Area clear of individuals and flight space is clear to fly.
24. Manually take-off and ascend to mission altitude. Verify good LOS to drone and
planned flight area.
25. Manually preform IMU in-air heading alignment maneuver.
26. Initiate mission via flight planning tool.
27. Monitor drone/True View during flight as per normal operations.
28. Upon completion of last flight line in the mission plan, allow the drone to start
the Return to Home sequence, but do not let it descend at the Home point. Toggle
drone to manual control (P->A->P) instead.
29. Manually preform IMU in-air heading alignment maneuver again.
30. Ensure landing area is still clear; complete the landing via Return to Home or manually
as preferred.
31. After landing, turn off drone.
