Signal
SDO = SDO_H
SDO = SDO_L
Master board:
SDO from J2
Slave board
SDO from J2 to
J4
Signal
ASC_L = GNDISO_L ASC pin shorted to GNDISO
ASC_L = OPEN
Signal
ASC_H = GNDISO_H ASC pin shorted to GNDISO
ASC_H = OPEN
Signal
SENSE_L = GNDISO_L SENSE pin shorted to GNDISO
SENSE_L = OPEN
Signal
SENSE_H = GNDISO_H SENSE pin shorted to GNDISO
SENSE_H = OPEN
Table 15.
Name
DEFAULT_L
UM3153 - Rev 1
Table 10. Jumper configuration of SPI chain
Function
Configuration of SPI daisy chain loop with two devices (HS+LS)
Suitable for:
• single board configuration with two device daisy chain.
See Section 4
• slave board closing the chain in multiple board
configuration. See Section 5
Configuration of SPI daisy chain loop with only one device (LS).
Suitable for single board configuration with only LS connected.
Configuration to leave open the SPI daisy chain loop and to
propagate SDO_H in multiple board configuration
Suitable in multiple board configuration for:
• the master board
• the middle slave board(s)
See Section 5
Table 11. Jumper configuration of LOW-side ASC bypass jumper
Function
ASC pin open, TP22 can be used to drive the signal
Table 12. Jumper configuration of HIGH-side ASC bypass jumper
Function
ASC pin open, TP49 can be used to drive the signal
Table 13. Jumper configuration of LOW-side SENSE bypass jumper
Function
SENSE pin open, TP21 can be used to drive the
signal
Table 14. Jumper configuration of HIGH-side SENSE bypass jumper
Function
SENSE pin open, TP48 can be used to drive the
signal
Jumper configuration for LOW-side DEFAULT function (Operation flow chart)
Function
DEFAULT PIN set LOW
Hardware description and configuration
Jumper configuration
JR11 = CLOSE
JR12 = OPEN
JR11 = OPEN
JR12 = CLOSE
JR11 = OPEN
JR12 = OPEN
Jumper configuration Default configuration
JR20 = CLOSE
JR20 = OPEN
Jumper configuration Default configuration
JR29 = CLOSE
JR29 = OPEN
Jumper configuration
JR21 = CLOSE
JR21 = OPEN
Jumper configuration
JR29 = CLOSE
JR29 = OPEN
Jumper configuration
JR22 = CLOSE
JR23 = OPEN
UM3153
Default
configuration
X
X
X
Default
configuration
X
Default
configuration
X
Default configuration
X
