Table 7. Jumper Configuration Of Pwm Input Signal (J3 Connector); Table 8. Jumper Configuration Of Diagnostic Diag1 (J7, J2, J4 Connectors); Table 9. Jumper Configuration Of Diagnostic Diag2 (J7, J2, J4 Connectors) - STMicroelectronics EVALSTGAP4S User Manual

Operating voltage
See STGAP4S Datasheet for
recommended values
PWM inputs
IN+_H = IN-_L
IN+_L = IN-_H
LS: IN+_L, IN-_L
HS: IN+_H, IN-_H
Signal
DIAG1
=
DIAG1_L
and
DIAG1_H
DIAG1 = DIAG1_L
DIAG1 = DIAG1_H
Signal
DIAG2
=
DIAG2_L
and
DIAG2_H
DIAG2 = DIAG2_L
DIAG2 = DIAG2_H
UM3153 - Rev 1
VL_H = 0V (VCC must be present, see
External power supply (from J6)
www.st.com
Table 7. Jumper configuration of PWM input signal (J3 connector)
Function
The LOW-side and HIGH-side drivers are
interlocked. Configuration for cross conduction
prevention.
The LOW-side and HIGH-side drivers are separate.
No cross conduction prevention.
Table 8. Jumper configuration of diagnostic DIAG1 (J7, J2, J4 connectors)
Function
The DIAG1 signal is the cumulative of the open drain outputs
DIAG1_L and DIAG1_H.
LED1 and LED3 are driven according to DIAG1
Only DIAG1_L is reported to the DIAG1 signal.
LED1 is driven according to DIAG1=DIAG1_L
LED3 is driven according to DIAG1_H
Only DIAG1_H is reported to the DIAG1 signal.
LED1 is driven according to DIAG1_L
LED3 is driven according to DIAG1=DIAG1_H
Table 9. Jumper configuration of diagnostic DIAG2 (J7, J2, J4 connectors)
Function
The DIAG2 signal is the cumulative of the open drain outputs
DIAG2_L and DIAG2_H.
LED2 and LED4 are driven according to DIAG2
Only DIAG2_L is reported to the DIAG2 signal.
LED2 is driven according to DIAG2=DIAG2_L
LED4 is driven according to DIAG2_H
Only DIAG2_H is reported to the DIAG2 signal.
LED2 is driven according to DIAG2_L
LED4 is driven according to DIAG2=DIAG2_H
Supply voltage source
Table 4)
Jumper configuration
JR13 = CLOSE
JR14 = CLOSE
JR13 = OPEN
JR14 = OPEN
UM3153
Hardware description and configuration
Default
Jumper configuration
configuration
JR27 = CLOSE
JR28 = CLOSE
JR26 = DON'T CARE
JR27 = CLOSE
JR28 = CLOSE
Default configuration
X
Default
Jumper configuration
configuration
JR7 = CLOSE
JR8 = CLOSE
JR7 = OPEN
JR8 = CLOSE
JR7 = CLOSE
JR8 = OPEN
Default
Jumper configuration
configuration
JR9 = CLOSE
JR10 = CLOSE
JR9 = CLOSE
JR10 = OPEN
JR9 = CLOSE
JR10 = OPEN
X
X
page 11/28
