Studio One Tutorial
V-Pot Assignment Modes
UF1 offers direct access to Studio One's four main Mackie Control V-Pot assignment modes. These V-Pot assignment modes are
accessed via the keys labelled below: 1. PAN, 2. SEND, 3. PLUGIN and 5. TRACK.
1
The Pan Key is located on
the Soft Key above the Small
LCD
1 - PAN
Assigns the Pan controls to the V-Pots on UF1. Pushing a V-Pot will default it to the centre position.
2 - SEND
Assigns the Send controls to the V-Pots. Pushing the V-Pot defaults the Send to 0 dB.
The first press of the SEND key will place the Sends of the selected track across the V-Pots and their values will
be displayed in the LowLCD zone. This send mode is indicated by SE in the 2-digit V-Pot assignment mode display
area. Use the 5-8 key to access sends 5-8 on the selected track.
Repeatedly pressing the SEND key will cycle the V-Pots through controlling a specific Send 'slot' across all tracks
at once. This send mode is indicated by S1, S2, S3, S4 etc in the 2-digit V-Pot assignment mode display area.
3 - PLUGIN
Set the V-Pots to 'Control Link' mode to control plug-ins but you must map your desired plug-in parameters first. See the next page.
4 - TRACK
The V-Pots allow you to control a number of functions of the selected track:
• V-Pot 1 - Bypass All FX Insert Slots
• V-Pot 2 - Monitor on/off
• V-Pot 3 - Input Source
• V-Pot 4 - Output Source
• V-Pot 5 - Send Slot 1 Bypass (5-8 key engaged to access)
• V-Pot 6 - Send Slot 2 Bypass (5-8 key engaged to access)
• V-Pot 7 - Send Slot 3 Bypass (5-8 key engaged to access)
• V-Pot 8 - Send Slot 4 Bypass (5-8 key engaged to access)
90
2 3
Send & Plug-in is available on Soft
Key Page 1
4
Track is available on Soft Key Page 2
