6 - Short Label
Using your computer keyboard, you can type the label that you wish to appear on the UF1 LCD just below the User Key.
7 - Profile Name and SAVE/LOAD/SAVE AS Buttons
Allows you to save your customised DAW profiles as an .xml file to your computer or any connected hard-drives. The name of the
currently active profile is shown above these buttons. If you have made any changes to the saved profile, then 'unsaved changes'
will appear beneath the profile name
Built-in Auto-Saving Feature
Changes you make to the software are automatically stored in the background, so you don't need to worry about remembering to
save each time you change something in SSL 360° software.
User-Assignable Keys
A number of keys on UF1 are user-assignable and can be changed from their factory shipped assignments. Each UF1 unit has
the following user-assignable keys:
• 10 pages of 4 x Top-Row Soft Keys (40 keys total)
• 6 x Secondary Transport Keys
• 2 x Foot-switches
All of these keys can have either DAW commands or keyboard shortcut sequences assigned to them.
Assigning DAW Commands
Clicking on the pen symbol for any user-assignable key will bring
up a pop-up window, from which DAW command can be selected
using the radio buttons on the left-hand side. To assign a different
DAW command to the button in question, simply select one from
the list of available HUI/MCU commands. The SHORT LABEL text
field allows you to enter the label you want to appear on the LCD to
accompany this command. The list of available commands depends
on the selected DAW.
Assigning Keyboard Shortcut Sequences
If you would like to assign a keyboard shortcut or shortcut sequence,
select the Keyboard macro option. Once selected, simply click your
mouse cursor into the area that says 'Type your commands here...'
and use your keyboard to enter the desired key press or sequence.
When adding a sequence of multiple commands, you can enter a
delay at the start of each line. This can be useful for certain DAW
operations where DAW windows or menus are sometimes slow to
open - it means you can add delays where necessary to ensure the
sequence is properly executed (not executed too quickly).
Should you make a mistake and need to start again, you can use
the CLEAR ALL button. Alternatively, you can use the individual
X buttons to delete particular lines. The SHORT LABEL text field
allows you to enter the label you want to appear on the LCD to
accompany this keyboard shortcut sequence.
