31-Band Real-Time Analyser (RTA)

The RTA screen is the place to view the frequency content of your material.
Meter Screen
Selector
Selected
Frequency:
Current & Max
Value Text
Readouts
31-Band
RTA
Selected
Meter Plug-in
Instance
Meter Plug-in
Selector
Meter Screen Selector - Press the key to toggle through the 3 different meter screens: Overview, Analogue and RTA.
Reset - Resets all metering, including clip indicators and max values.
Fine Encoder Mode - Puts the encoders into fine resolution mode for precise adjustments.
Presets Menu - Opens a menu where you can load your Meter plug-in presets from by scrolling with the 4th encoder and pushing
to confirm the load.
Page
1
2
3
130
Reset
Parameter
Control 1
Meter Plug-in Selector
Scroll to select the Meter
plug-in instance
Fine
Encoder Mode
Parameter
Control 2
Parameter Control 1
Select Frequency
Peak Hold Time
Analysis Source
Presets
Menu
Parameter
Control 3
Parameter Control 2
Scale Top
Weighting
-
Peak
Current
Meter Plug-in
Parameters
V-Pots
Parameter Control 3
Scale Bottom
RTA Averaging
-
