Solid State Logic SSL UF1 User Manual page 105

LUNA Tutorial
V-Pot Assignment Modes
UF1 offers direct access to LUNA's Mackie Control V-Pot assignment modes. These V-Pot assignment modes are accessed via
the keys labelled below: 1. PAN, 2. SENDS, 3. CUES.
2 3
1
The Pan Key is located on
the Soft Key above the Small Sends & Cues are available on Soft Key Page 1
LCD
1 - PAN
Assigns the Pan controls to the V-Pots on UF1. Pushing a V-Pot will default it to the centre position.
2 - SEND and 3 - CUES
These assign the V-Pots to LUNA's Sends and Cues. You can cycle through the various modes for controlling
sends by repeatedly pressing each button (SENDS or CUES). Or you can push and hold either key and whilst
keeping the key held, push the relevant V-Pot to control a particular send slot. Use in conjunction with the 5-8
key to access all send parameters or send slots
SSL UF1 User Guide
105
