Connecting Your UF1 Hardware

1. Connect the included power supply to the DC socket on the connector panel.
2. Connect one of the included USB cables from your computer to the USB socket.
USB Cables
Please use one of the provided USB cables ('C' to 'C' or 'C' to 'A' with the provided adapter) to connect UF1 to your computer. The
type of USB port you have available on your computer will determine if the adapter is required for connecting the cable to your
computer. Newer computers may have 'C' ports, whereas older computers may have 'A'. Please ensure that you are connecting
to the port labelled USB on UF1 which is a 'C' type connection.
Connecting the UF1 to UF8
If you are using a UF1 and a UF8, you can use the THRU port (USB 'A' type) to link the two devices - this means that only one USB
port is required at your computer.
Theoretically, you can chain 4 x UF8, a UC1 and a UF1 together in the way described above. However, by doing so you may exceed
the number of hub tiers permitted by your PC/Mac computer. As such, you may need to connect your UF1 unit directly to another
USB port on your computer. The same applies regarding the use of USB hubs; the UF1 may need to be plugged directly into a
different USB port on your computer.
Tip: The THRU port can also be used to plug in USB dongles for DAW software or plug-in licenses.
8
Power Supply
UF1 Connector Panel
UF1
C to C cable
or C to A cable
A to C USB Cable
UF8
