Table Of Contents - Adey MagnaClean CMX MIDI PRO ASSIST Installation And Servicing

Contents
Checklist
Location
Key Features
Unit Installation
Electrical Installation/Earthing
Controller Wiring Diagrams
Operation
Controller Programming Parameters
Filtration & Pressure Differential Monitoring
Flow & Temperature Measurement
Maintenance & Servicing
Environment Protection
Technical Specification
Troubleshooting Guide
UK Declaration of Conformity
Product Description
Heating & chilled system sidestream and pumped sidestream filtration units with integrated MagnaClean
CMX Midi filter; automated control system with BMS connectivity options providing connected system/
filtration monitoring via constant system flow, pressure differential and temperature sensing.
Application
The MagnaClean CMX Midi Pro & Midi Pro Assist Sidestream filters provide high performance,
sidestream filtration for all heating & chilled systems. Featuring a high performance MagnaClean CMX
Midi filter, the option of an integrated Grundfos UPM3 Flex AS pump for pumped, assisted filtration
and the security of system flow, pressure differential and temperature sensing with full BMS alarm
connectivity, these solutions are designed to actively monitor the system and the active filtration of
any heating or chilled system in a sidestream configuration for 24 hours a day.
Transport/Storage
These units are heavy - care should be taken during lifting & handling. During transportation,
secure the units properly to prevent any damage. If this product is not being installed immediately,
ensure it is stored in a dry, frost & vibration-free location in its original packaging.
The WEEE symbol on this product indicates that the product must not be disposed of with normal
household waste. Instead such marked waste equipment must be disposed of by arranging to return
to a designated collection point for the recycling of waste electrical and electronic equipment.
This MagnaClean CMX Midi filter contains a strong magnet.
Keep away from all electrical devices, bank cards and other magnetic devices.
This MagnaClean CMX Midi filter contains a strong magnet.
Caution should be taken at all times when handling if you have a pacemaker fitted.
This MagnaClean CMX Midi filter is a pressurised device.
Always release pressure before servicing.
The filter unit may be hot in operation.
Handle with care.
THIS PRODUCT COMPLIES WITH ALL CURRENT UK and EU PRODUCT LEGISLATION.
2
3
4
5
6
8
10
11
12
19
20
21
23
24
26
28
