ADEY DEK1002 MODBUS PROTOCOL - VARIABLE LIST
DEFAULT SETTINGS
BAUD RATE
WORD LENGTH
PARITY
STOP BITS
X Variable Denomination
Address
40001 Cartridge Present
40002 Magnet Only Service Warning
40003 Magnet Only Service Warning
Duration
40004 Parameter Pressure Difference
Warning
40005 Parameter Pressure Difference
40006 Parameter Flow Monitoring
Enable
40007 Parameter Low Flow Warning
40008 Parameter Low Flow Alarm
40009 Parameter Minimum Pressure
40010 Parameter Maximum Pressure
40011 Parameter Temperature Alarm
Enable
40012 Parameter Low Temperature
Alarm
40013 Parameter High Temperature
Alarm
40014 Parameter Pump Required
40015 Parameter Current Sense Active
40016 Parameter Alarm Relay Contact
Type
40017 Parameter ID Number
40018 Parameter Battery Activated
40019 Service Date Day
40020 Service Date Month
40021 Service Date Year
40022 Last Serviced Date Day
40023 Last Serviced Date Month
40024 Last Serviced Date Year
40025 Magnet Only Service Day
40026 Magnet Only Service Month
40027 Magnet Only Service Year
16
9600
8
NO
1
Type X Variable
Format
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read/write word 16 bits
read word 16 bits
read word 16 bits
read word 16 bits
read word 16 bits
read word 16 bits
read word 16 bits
Data Conversion Units Equivalent
Range
4 = No 5 = Yes 4->6
6 = FastFast
11 = Daily 12 = Weekly 11->13
13 = Monthly
Value = X 1->12
Value = X/10 Bar 0,1-0,6
Value = X/10 Bar 0,1-6,0
4 = No 5 = Yes 4-5
Value = X l/min "0->
Parameter
Low Flow
Alarm"
Value = X l/min Parameter
Low Flow
Warning ->
200
Value = X/10 Bar "0 ->
Parameter
Maximum
Pressure"
Value = X/10 Bar "Parameter
Minimum
Pressure
>-6,0"
4 = No 5 = Yes 44685.00
Value = X °C "0->
Parameter
High Temp
Alarm"
Value = X °C "Parameter
Low Temp
Alarm >120"
4 = No 5 = Yes 4-5
4 = No 5 = Yes 4-5
0 = Norm. Open 0-1
1 = Norm. Close
Value = X 0-99
4 = No 5 = Yes 4-5
Value = X 1-31
Value = X 1-12
Value = X 0-99
Value = X 1-31
Value = X 1-12
Value = X 0-99
Value = X 1-31
Value = X 1-12
Value = X 0-99
Range of Notes
X Variable
4->6
11->13
1->12
1-6
1-60
4-5
"0->
Parameter
Low Flow
Alarm"
Parameter
Low Flow
Warning ->
200
"0 ->
Parameter
Maximum
Pressure"
"Parameter
Minimum
Pressure
->60"
4-5
"0->
Parameter
High Temp
Alarm"
"Parameter
Low Temp
Alarm >120"
4-5
4-5
0-1
1-99
4-5
1-31
1-12
0-99
1-31
1-12
0-99
1-31
1-12
0-99
