Adey MagnaClean CMX MIDI PRO ASSIST Installation And Servicing page 17

X Variable Denomination
Address
40028 Parameter Pump Hours
40029 Current Water Flow
40030 Water Flowed Last 24 Hours
(thousands)
40031 Water Flowed Last 24 Hours
(units)
40032 Water Flowed since Last
Pressure Alarm (Billions)
40033 Water Flowed since Last
Pressure Alarm (Millions)
40034 Water Flowed since Last
Pressure Alarm (Thousands)
40035 Water Flowed since Last
Pressure Alarm (Units)
40036 Total Water Flowed (Billions)
40037 Total Water Flowed (Millions)
40038 Total Water Flowed (Thousands) read/write word 16 bits
40039 Total Water Flowed (Units)
40040 Actual Day
40041 Actual Month
40042 Actual Year
40043 Actual Hours
40044 Actual Minutes
40045 Pump Status
40046 Common Alarm Status
40047 LED Alarm Status
40048 Alarm Pump Failure
40049 Alarm Excessive Differential
Pressure
40050 Low Flow Warning
40051 Low Flow Alarm
40052 Alarm Maximum Pump Activity
40053 Alarm Low Temperature
40054 Alarm High Temperature
40055 Warning Differential Pressure
40056 Magnet Only Service Warning
40057 Pressure
40058 Temperature
40059 Flow
40060 Save the changes in Flash
Memory
NOTE 1. All writings via ModBus will affect the values of the variable in volatile memory. To save changes to parameters in permanent
memory, write the value 111 to address 40060
NOTE2. 1 is equivalent to 24 hours
Type X Variable Data Conversion
Format
read/write word 16 bits Value = X
read word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits Value = X
Value = X
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read/write word 16 bits Value = X
read word 16 bits 0 = OFF 1 = ON
read word 16 bits 0 = OFF 1 = ON
read word 16 bits 0 = OFF 1 = ON
read word 16 bits 0 = Not Active
1 = Active
read word 16 bits 0 = Norm. Open
1 = Norm. Close
read word 16 bits 0 = Not Active
1 = Active
read word 16 bits 0 = Not Active
1 = Active
read word 16 bits 0 = Norm. Open
1 = Norm.Close
read word 16 bits 0 = Not Active
1 = Active
read word 16 bits 0 = Norm. Open
1 = Norm. Close
read word 16 bits 0 = Not Active
1 = Active
read word 16 bits 0 = Not Active
1 = Active
read word 16 bits Value = X/10
read word 16 bits Value = X
read word 16 bits Value = X
read/write word 16 bits Value = X
Units Equivalent Range of
Range X Variable
Days 0-9999 0-9999
l/min 0->200 0->200
Khours 0->999 0->999
hours 0->999 0->999
Bhours 0->999 0->999
Mhours 0->999 0->999
Khours 0->999 0->999
hours 0->999 0->999
Bhours 0->999 0->999
Mhours 0->999 0->999
Khours 0->999 0->999
hours 0->999 0->999
day 1->31 1->31
month 1->12 1->12
year 0->99 0->99
hours 0->23 0->23
min 0->59 0->59
0-1 0-1
0-1 0-1
0-1 0-1
0-1 0-1
0-1 0-1
0-1 0-1
0-1 0-1
0-1 0-1
0-1 0-1
0-1 0-1
0-1 0-1
0-1 0-1
Bar Par.3 - Par.4 Par.3 - Par.4
°C 0-120 0-120
l/min 0->200 0->200
"Write 111 "Write 111
to save to save
in Flash in Flash
Memory" Memory"
Notes
NOTE 2
NOTE 1
