SUMMARY
PRODUCTS TO BE USED IN MULTIPLE SYSTEM
1. Number of video amplifiers to be used in MULTIBUS system
it is only used for column cable installations and is required to be placed near the door panel, 5 columns
need 1 piece.
2. Number of MB-DIST video distributors to be used in MULTIBUS system
The junction box is used to connect 1 MB-DIST video distributor to each floor in horizontal installations.
3. Number of PS-18E adapters to be used in the MULTIBUS system
1 PS-18E for up to 40 apartments
2 PS-18E for up to 100 apartments
1 RED-18E for more than 100 apartments in
4. Number of cables to be used in the MULTIBUS system
NUMBER OF FLOOR
Up to 6 times (max. 40 monitors) (longest cable
cable approx. 30 m)
more floors
Up to 12 floors (max. 80 monitors) (longest cable
cable approx. 50 m)
More floors
DATE: 14.02.2019 REVISION DATE:
CABLE TO BE USED
CAT5/CAT6/CAT8 OR MULTİTEK DT5
MULTİTEK DT5 or H03VH-H 1X2X1 mm2 and
KPD-V 3X0.5 mm2
H03VH-H 1X2X2.5 mm2 and KPD-V 3X0.5 mm2
