17.11.5 Powered Drive
CAUTION!
Damage to property due to incorrect transport and involuntary movement!
►
Prior to transport, ensure that the Sprint 200 with i-Drive Power is disconnected from the mains.
►
Hang the mains cable on the appropriate hook on the Sprint 200 with i-Drive Power during transport.
►
Ensure that the castors are locked prior to putting into service, removing from service and maintenance of the
i-Drive Power system.
►
Ensure that the castors are locked when the stretcher is occupied.
Instructions for Powered Drive:
1.
Check, if the mains switch of the i-Drive Power is activated (i-Drive Power Mains Switch is in ON position).
2.
Press green Drive pedal to the lower position. The braked i-Drive Power wheel will lower.
3.
Press the button
4.
Place your hand on the Safety Sense touch sensor.
5.
Push the button
i-Drive Power. If released, the i-Drive Power will stop.
6.
The i-Drive Power motor is immediately stopped after pressing the red button
7.
i-Drive Power control system is automatically deactivated if no i-Drive Power function is used for 3 minutes. This is signali-
zed by the green LED
NOTE
i-Drive Power is not designed for ascending or descending a slope greater than 6° or longer than 20 m. The support of
personnel is needed when ascending or descending with a full SWL.
NOTE
When i-Drive Power wheel is lowered, it is not possible to move the stretcher forward. Press or lift a pedal to leave all
Brake pedals and Drive pedals unpressed in their neutral middle position or brake the stretcher to retract the i-Drive Power Wheel
and then move the stretcher to any direction required.
17.11.6 Braking
1.
Press and hold the button
-or-
2.
Press and hold the button
-or-
3.
Release your hand from the touch sensor area and i-Drive Power will brake automatically.
NOTE
Always brake the stretcher by using the castor control lever when the transport is finished or interrupted. The i-Drive Po-
wer electromagnetic brake is not designed to permanently brake the stretcher.
NOTE
In a crisis situation (e.g. acceleration when driving down a steep slope) i-Drive Power dual braking prevents acceleration
and slows down stretcher movement. However, it is not guaranteed the stretcher will stop by itself without personnel support (using
button
and castor control lever).
NOTE
When descending, it is possible to actively brake using the opposite direction button to slow.
17.11.7 Free Drive
The i-Drive Power motor is equipped with free drive, which is active after pressing the forwards (
) buttons (until user holds the touch sensor area).
Free Drive is deactivated and the brake is activated when the direction of motion is changed. This is feature for lowering the risks
when going to a slope.
D9U001ES2-0101_05
on the i-Drive Power Main Control Panel. The ON LED
or button
or button
which is extinguished after 3 minutes.
to brake immediately.
to brake slowly (Press the button
. Your hand must be placed on the Safety Sense sensor to use the
to brake when reversing).
will be flashing.
when braking or in emergency.
or
) or backwards (
105
