ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Qty Reference Designator
21 C1, C4, C5, C8, C17, C18, C21, C22, C25, C29, C53,
C54, C55, C57, C60, C61, C62, C63, C64, C65, C66
13 C2, C3, C6, C7, C10, C16, C19, C20, C23, C24, C28,
C52, C56
9 C9, C33, C36, C38, C41, C43, C46, C48, C51
10 C11, C12, C26, C27, C30, C31, C34, C39, C44, C49
1 C13
3 C14, C58, C59
1 C15
8 C32, C35, C37, C40, C42, C45, C47, C50
1 D1
2 D2, D3
1 D4
2 D5, D6
5 J1, J2, J3, J4, J5
2 J6, J7
6 J8 to J13
1 J14
1 J15
1 J16
4 L1, L4, L5, L8
4 L2, L3, L6, L7
14 R1, R2, R13, R32, R33, R34, R35, R36, R37, R47,
R51, R52, R56, R58
13 R3, R5, R6, R8, R11, R14, R18, R46, R48, R53,
R54, R55, R57
1 R4
2 R7, R38
1 R9
1 R10
1 R12
4 R15, R16, R17, R19
8 R20, R22, R24, R26, R28, R30, R40, R42
4 R21, R25, R29, R41
4 R23, R27, R31, R43
3 R39, R49, R50
2 R44, R45
2 SW1, SW2
9 T1 to T9
1 U1
4 U2 to U5
1 U6
1 U7
1 Y1
1 Y2
Description
Capacitor, 0.1 μF, 10%, 0402, 16 V, X7R
Capacitor, 10 pF, 5%, 0402, 50 V, NPO
Capacitor+, 22 μF, 10%, TAJ_A, 6.3 V, tantalum
Capacitor, 1 nF, 10%, 0603, 50 V, X7R
Capacitor, 1.5 nF, 10%, 0603, 50 V, X7R
Capacitor, 22 nF, 10%, 0603, 50 V, X7R
Capacitor, 680 pF, 10%, 0603, 50 V, X7R
Capacitor+, 1 μF, 10%, TAJ_A, 16 V, tantalum
LED_CHIP, light emitting diode
SS16, DO-214AC, Schottky diode, −1 A, 60 V
Zener-diode-S, 6.8 V, 5%, SOT23, OT23
LED, LED_CHIP, light emitting diode
SMA, SMA_CARD_EDGE_RF
HEADER-7X2POL, HEADER14-POL
DNI, SMA_CARD_EDGE_RF
Red, 4 mm, banana socket
Black, 4 mm, banana socket
USB mini-B connector (usb-otg)
Inductor, 0 Ω, 1%, 0603
Inductor, 3.9 nH, 5%, 0603, Coilcraft 0603CS
Resistor, 0 Ω, 1%, 0603
Resistor, DNI, 1%, 0603
Resistor, 4.7 kΩ, 1%, 0603
Resistor, 1 kΩ, 1%, 0603
Resistor, 820 Ω, 1%, 0603
Resistor, 100 Ω, 1%, 0603
Resistor, 330 Ω, 1%, 0603
Resistor, 10 kΩ, 1%, 0603
Resistor, 220 kΩ, 1%, 0603
Resistor, 390 kΩ, 1%, 0603
Resistor, 120 kΩ, 1%, 0603
Resistor, 2.2 kΩ, 1%, 0603
Resistor, 100 kΩ, 1%, 0603
SW_POWER, SW_SIP-3P, NKK SPST N/O momentary push button switch
Testpoint
ADF4350, LFCSP-32 PLL
ADP3334 MSO8 adjustable LDO regulator
CY7C68013-CSP, LFCSP-56, USB microcontroller
2
24LC64, SO8NB, 64K I C serial EEPROM
OSC_TCXO, 10.0 MHz, OSC_TCXO, FOX
XTAL-CM309S, 24 MHz, XTAL_CM309S, CM309S SMD crystal
